with a connector, to the longer, thin black wire of the re-
lay.
5. The blue "antenna" wire remains unconnected.
Connecting the wired control of the winch
The wired control has three wires: red F and two other,
terminated with connectors: blue G and black I
1. Connect the red wire of the A pin on the relay.
2. Connect the blue G wire to the blue H wire of the
relay
3. Connect the black I wire to the black J wire of the
relay
F. CONNECTION FOR WINCH MODELS:
DWM 2000 ST
DWM 2500 ST
DWM 3500 ST
Connection diagram - see section F at the end of the ma-
nual.
The relay has four pins on the front panel A, B, C, D and
three connectors coming out of the relay housing: H, E, J.
Connection of power leads - battery - relay - motor
1. With the first pair of leads (red and black) make the
following connections:
- Use the red lead (a) to connect the pin with the C mark
on the relay with the power on the motor marked with a
42
"+" or with a red washer.
- Use the black wire (b) to connect the pin with the D
mark on the relay to the negative bolt on the motor marked
with a "-" or with a black washer.
2. With the second pair of leads (red and black) make
the following connections:
- Connect the red (c) pin A on the relay with positive (+)
battery terminal
- Connect the black (d) pin B on the relay with negative
(-) battery terminal
3. Connect the E connector of the relay with the B pin
of the relay
Connection of radio control (wireless).
The remote control consists of a radio signal receiver and
a transmitter (remote controller). There are five wires co-
ming from the receiver: red: K, black: L, white: N, yellow:
M, blue is the "antenna".
Connect the radio control as follows:
1. Connect the red K wire of the receiver with A pin on
the relay.
2. Connect the black L wire of the receiver with the B
pin on the relay.
3. Connect the white N wire of the receiver terminated
with the connector to the J connector of the relay.
4. Connect the yellow M wire of the receiver, termina-
ted with a connector to the H connector of the relay.
5. The blue "antenna" wire remains unconnected.
