Symbols on the unit

Installation and connection

Reassembling the unit
How to proceed:
1. Fit the sleeve, flow regulator, double nipple, union nut, ball joint and transition piece together
and screw onto the pump outlet.
2. Screw the telescopic extension with the desired nozzle onto the flow regulator.
3. Screw the stepped hose adapter onto the flow regulator for feeding a water course if applica-
ble.
4. Align the telescopic extension and hand tighten the union nut on the ball joint.
The unit is dust-tight and water-tight down to 2 m.
Remove the unit in the event of freezing temperatures.
Danger for persons with pacemakers. The unit contains a strong magnet.
Do not dispose of the unit with the normal household waste.
Read the operating instructions.
EN
ARS0019
17
