Parts (Before beginning, make sure you have all parts shown below).
ESP
Piezas (antes de iniciar, asegúrese de tener todas las piezas siguientes).
FRN
Pièces (avant de commencer, assurez-vous d'avoir toutes les pièces illustrées ci-dessous).
DEU
Teile (Achten Sie vor Beginn der Arbeiten darauf, dass alle unten abgebildeten Teile vorhanden sind).
NEL
Onderdelen (hoort u zich ervan te overtuigen dat u alle onderdelen hebt, die hieronder te zien zijn).
ITL
Parti (prima di iniziare, accertarsi di disporre tutte le parti sotto indicate).
ČEŠ
Díly (předtím, než začnete, připravte si všechny díly zobrazené níže).
SLK
Diely (predtým, ako začnete, pripravte si všetky diely zobrazené nižšie).
Peças (antes de iniciar, certifique-se de que tem todas as peças apresentadas em baixo).
POR
Parçalar (Başlamadan önce, aşağıda gösterilen bütün parçaların elinizde olduğundan emin olun).
TÜR
Parts List
Description
A wall plate
B right adapter bracket
C left adapter bracket
D 8mm concrete anchor
E #14 x 2.5" wood screw
F M6 x 12mm
G M6 x 25mm
H M8 x 12mm
I M8 x 25mm
J M6/M8 washer
K spacer
L 4mm allen wrench
M M8 x 50mm
D ( 6 )
8mm concrete anchor
#14 x 2-1/2" wood screw
F ( 4 )
M6 x 12mm
J ( 8 )
M6/M8 washer
ST670
Qty
Part #
1
096-SG1573
1
096-SG1595
1
096-SG1590
6
590-0320
6
5S1-015-C03
4
520-1050
4
520-1211
4
520-1724
4
520-1101
8
540-9406
8
600-1215
1
560-1145
4
521-1013
E ( 6 )
G ( 4 )
M6 x 25mm
K ( 8 )
spacer
ST670P
Part #
right adapter bracket
096-SG1573
096-SG1595
096-SG1590
590-0320
5S1-015-C03
520-1128
520-1208
520-9571
520-1031
540-9406
600-1215
560-1145
521-1009
L ( 1 )
4mm allen wrench
H ( 4 )
M8 x 12mm
M (4)
M8 x 50mm
6
B (1)
C (1)
left adapter bracket
A (1)
wall plate
I ( 4 )
M8 x 25mm
2016-08-30
