05. FUNCTION DIAGRAM

When the machine is running, the display window automatically
switches every 5 seconds. The indicator light at the bottom of the luli
window changes with the display of the window. The information
displayed in different Windows is as follows:
(1). "Speed" window
The current speed value is displayed in the running state, and the speed is on. The display range is 1-7.5mph.
（1）When the column pillar is open, the maximum speed is 7.5mph
（2）When the column pillar is closed, the maximum speed is 3.8 mph
(2). "Time" window
Display exercise time. The time range is 0:00-99:59 minutes,Maximum display 18h.
(3). "Distance" window
Display the moving distance, the display range is 0.00-9999mp miles, the reverse count is decremented from the set value to zero, when the
counter turns to 0, the machine will steadily descend to stop.
(4). "Calories window"
Display the calorie consumption value, the display range is 0.0-9999 kcal.
The reverse count is decremented from the set value to zero, when the counter turns to 0, the machine will steadily descend to stop.
06
Sports suggestions and guidelines
Stop Button Speed Decrease buttons
Speed Shortcuts: 6MPH
Start/Pause button
Speed Shortcuts: 3MPH Speed Increase buttons
05. FUNCTION DIAGRAM
WIFI indicator
ON/OFF
Bluetooth indicator
Speed-
Speed Display
Remote control
Time Display
(1). Press the "Speed -" key to reduce the machine speed.
(2). Press "Speed +" to increase the speed of the machine.
Distance Display
(3). Press the "ON/OFF" button, and the machine will start or stop slowly.
1. In the standby state, directly press the "ON/OFF" button, the treadmill would start to move at the
Calorie Display speed of 0.2 miles/hr, other windows start counting up from 0, press "+","-" button to change the
speed.
Unmanned Shutdown:
In the operating state of the treadmill, if the treadmill detects an unmanned state for more than 10s, it will automaticallystop.
Speed+
