ENGLISH
4-step mode with HF-igni-
tion
Stick electrode welding
Stick elevtrode welding and
Arc-Force function
Welding current
Upslope function
Downslope function
Gas postflow time
Fault
Excess temperature
Connector for remote con-
trol unit
Connector for TIG torch
Connector for TIG torch gas
hose
Connector for gas supply
Main switch
Information on rating plate:
1
2
3
7
1 Manufacturer
2 Machine designation
3 Serial number
4 Standard information – This
machine meets the requirements
of the standards mentioned
5 CE mark – This machine con-
forms to EU directives as per
declaration of conformity
6 Electrical performance data
7 Year of make
10

3. Operating Elements

8 Carrying strap/shoulder strap
Adjustable in length for carrying
9 Welding current connector
(+ pole)
10 Connector for torch gas hose
11 Welding current connector (-
12 Connector for TIG torch
pilot lead
13
4 5
13 Mode button
For operating mode selection.
14 2T+HF
LED lit when selected.
6
15 4T+HF
LED lit when selected.
16 Stick electrode welding
LED lid when selected.
17 Stick electrode welding with
Arc-force
LED lid when selected.
18 LED display
Displays the current value of
the selected parameter.
19 Parameter button
For parameter selection.
12
11
− by hand (shown in illustra-
tion)
− on the shoulder.
pole)
14 15
18
22 23
17 16 21 20 19 25 24
20 Minus button
Decreases the displayed value.
21 Plus button
Increases the displayed value.
8
22 Welding current I indicator
− LED lid:
Welding current available,
can be changed.
− Flashing:
Welding current active.
23 Upslope indicator
− LED lid:
9
Parameter
changing.
10
− LED flashing:
Current is sloping up.
24 Downslope indicator
− LED lid:
Parameter
changing.
− LED flashing:
Current is sloping down.
25 Gas postflow time indicator
− LED lid:
Parameter
changing.
− LED flashing:
Gas postflow time is active.
26 Fault indicator
− LED lid:
Machine has detected a
26 fault and shuts down.
27 Excess temperature indicator
− LED illuminated:
Excess temperature fuse
tripped and control disa-
bled.
28
27
29
30
31
28 Master switch
Switches unit ON or OFF
29 Socket for remote control unit
30 Gas supply connector
31 Power supply cable
LED = Light-Emitting Diode, used as
indicator light.
