4.2 Diagrams

IoT Antenna
IoT Indicator
REV Indicator
RUN Indicator
IoT/Reset Button
CT1 Input
CT2 Input
AC Power Input
1. IoT Antenna
2. IoT Indicator
The green light flashes while pairing and will stay lit when the device is
paired.
3. REV Indicator
Indicates reverse power to grid.
4. RUN Indicator
5. IoT/Reset Button
Press the button for 3 seconds to pair and connect to a Wi-Fi network, press
and hold for 10 seconds to factory reset.
6. CT1 Input
7. CT2 Input
8. AC Power Input
