DPAS-2100
Hedge Trimmer blades are sharp. Always wear gloves when adjusting
cutting assembly.
DO NOT stand hedge trimmer on end when adjusting cutting angle,
otherwise serious injury may result.
1. Place unit on a flat surface with
blade guard (A) facing up. Assure
stop switch is in the "STOP"
position.
2. Grab blade adjustment handle (B)
and compress blade lock levers
(C) and (D) together. Rotate blade
to desired position. Release the
levers to lock the blade.
Gear case assembly becomes HOT during use. Always grip assembly
at blade-adjustment handle when making cutting angle adjustments,
otherwise serious injury may result.
Always install the blade cover for storage or transportation.
Rotate Cutter Assembly:
Always use the unit from the right-hand side of your body – NEVER from the
left side. Rotate cutter assembly 180° on drive shaft in order to avoid cutting
directly above your head.
99922238047
© 12/2022 ECHO Incorporated
SAFETY
A
C
B
D
