EN Functions & Settings

Levelling the machine

Using a spirit level check that the appliance is firm and level and does not rock. Turn the locking nut A
clockwise to release it. Rotate the foot as required and finally lock the nut A again against the base of the
appliance.

Connection to the water supply

Connect one end of the inlet supply hose to a threaded 3/4" BSP isolating tap connector and ensure that it is
fully tightened. Connect the other end to the inlet connector at the top of the back of the appliance. Add the
hose clip and screw 04. x1 to the carcass to cover the connector.
04. x1
IMPORTANT: This appliance requires adequate backflow protection to ensure
waste water from the appliance cannot enter the potable water supply of your
property.
During installation, you must ensure that there is adequate backflow protection to ensure local water
regulations are met in the country where the appliance is used. This includes the use of additional
components such as double-check valves and hose sets that must comply with EN 1717 or EN 61770.
Only use the hose supplied with the appliance and do not use old hose sets.
