Overview
pendently control scanners and a half mirrored sphere on
the bottom. Equipped with 8 x RGBW 10W LEDs, it generates
ment delivered by its mirrors, and the previously mentioned
sphere, both huge coverage and visual impact are guaran-
parties and a wide variety of small/medium applications.
Source & Optics
Light Source: 10 10W RGBW( 2R, 2G, 2B, 2W) LEDs
LEDs life: 50,000 hs.
Great coverage LED Centerpiece
Built-in mirror ball
60º tilt mirrors
Great velocity & precision scanners
Dimmer: Full range 0-100%
Optimized Sound-active mode
Control
Operational modes: Sound Active, Auto-run, DMX, Master/
Slave
DMX Channels: 21
High-speed stepper motors
Built-in microphone
Operating temperature: 10ºC~40ºC
Physical
4-digit LED display
Power supply connector: Interlock In
DMX connectors: 2 XLR connectors (XLR-3 In and Out)
Dimensions: 540x540x255 mm. / 21.2x21.2x10 in.
Weight: 5.5 Kg. / 12 Lbs.
DISCO SCAN
ENGLISH VERSION
-
-
p. 2
