MACHINE STRUCTURE (Continues)
21. Solution tank
22. Solution tank filler plug
23. Removable solution feed hose
24. "Garden" intake for loading the solution
25. Solenoid valve
26. Disc brush deck
27. Brush
28. Solution valve:
A) Open valve
B) Closed valve
30
33
21
36
29
B
A
09/2017
28
INSTRUCTIONS FOR USE
29. Squeegee
30. Debris collection tank
31. Vacuum grid with automatic shut-off float
32. Vacuum system motor
33. Recovery tank
34. Recovery water tank cover (open)
35. Machine forward speed adjusting knob
36. Batteries (optional)
35
9100002290 - SC401
ENGLISH
34
31
32
