TECHNICAL DESCRIPTION
Options
Carrier
Axles 8 x 8 x 8
Counterweight „c" transport
storage on carrier tail
Wheels 44595 174F
Wheels 52580 179E
Auxiliary heating engine
independent carrier 10
Air condition carrier 7
Crane
Telescopic boom HA60
Remote control RK
S1V
H2X
Counterweight NEG21
Additional counterweight EG
Additional counterweight NEG 4.7 t, 1 piece; For max. 26.1 t à 8 pieces; Only in combination with counterweight NEG21.
Quick connection HA 2
Outrigger load indicator
Outrigger basis monitoring
Moving out of crane cab
Auxiliary heating engine
independent crane 5
Air condition crane 7
Extensions
HAV19
HAV-HY
VA8
MSF2
R1
Diverse
Refinery package 2M
Dolly preparation 4PV
Hook block 100-7-18-D
Hook block 80-5-18-D
Hook block 80-5-18-E
Hook block 50-3-18-D
Hook block 50-3-18-E
Hook block 20-1-18-E
Hook 8-0-18-E
43
8 x 8 x 8; All 4 axles steered and permanently driven and equipped with selectable transverse lock.
Support frame for storing counterweight „c" à 3.2 t on carrier tail; Required to carry 10.1 t, 13.8 t or 15.3 t
counterweight on board.
445/95R25 174F (16.00R25); Steel rims 11,00-25/1,7" CR.
525/80R25 179E (20.50R25); Steel rims 17,00-25/1,7" CR; Incl. carrier broadening to 2.75 m.
Auxiliary, engine independent Diesel heating system with 10 kW heating power; With timer; Switchable
between engine block and carrier cab.
Air condition for carrier cab with 7 kW cooling power.
12.0 m - 59.4 m; Single cylinder telescoping system, automatic telescoping; Attachments for all equipment
and extensions; 5 sheaves integrated in boom head for max. capacity of 64.5 t.
Full control of rigging and crane movements via wireless remote control.
Heavy lift attachment stage 1; 2-sheave; Dis-/connectable; For total 7 sheaves at boom head and max.
capacity of 80 t.
2. hoist; Spring-loaded multi-disc brake; Resolver (hoist rotation indicator); Incl. quick couplings and
transport storage; Self-rigging; Enables 2-hook operation with all extensions.
Version for countries with special road regulations; Enables self-downrigging < 40 t total weight and axle
loads < 12 t; Total 21.4 t à 7 pieces; Automatic rigging system, expandable to max. 26.1 t; Individual
technical verification required.
4.8 t, 2 pieces; For max. 26.1 t à 8 pieces; Only in combination with counterweight EG21.
Hydraulic bolt extractors and hydraulic and electric quick couplings for fast (dis-) assembly; Incl. transport
storage for luffing cylinder.
Displayed in LMI crane cab.
Surveillance of each outrigger beam for visual comparison with the programmed outrigger basis; Displayed
in LMI crane cab (Attention – there is no automatic linkage with the LMI system).
Control of carrier out of crane cab, enables machine moving when rigged, possible even under load.
Auxiliary, engine independent Diesel heating system with 5 kW heating power; With timer and remote
start; Switchable between engine block and carrier cab.
Air condition in crane cab with 7 kW cooling power.
10 m / 19 m; Double folding swing-away jib, manual offset 20° / 40°; 1-sheave head; Incl. transport storage;
Includes HAV10; Operation with HA or VA.
Hydraulic, stepless offset 0°-40°, instead of the manual offset; For HAV10, respectively HAV19.
8 m; Variable telescopic boom extension, manual offset 20° / 40°; Operation with HAV(-HY)19.
1.5 m; Fixed assembly jib, 2-sheave for max. capacity 26.6 t; Incl. transport storage at boom head.
Swing-away rooster sheave; Incl. transport storage; For single-reeving operation with elevated hook height.
Engine emergency stop device, with air shut-off damper, for carrier and crane.
4-point support brackets enable individual positioning of a dolly; Incl. freewheel for slewing gear unit and
luffing cylinder, quick couplings for brake air and electrics; Dolly and dollyadapter are not included.
100-7-18-D (750 kg); Hook block with ramshorn hook; white with red signal stripes.
80-5-18-D (650 kg); Hook block with ramshorn hook; white with red signal stripes.
80-5-18-E (650 kg); Hook block with single hook; white with red signal stripes.
50-3-18-D (550 kg); Hook block with ramshorn hook; white with red signal stripes.
50-3-18-E (550 kg); Hook block with single hook; white with red signal stripes.
20-1-18-E (300 kg); Hook block with single hook; white with red signal stripes.
8-0-18-E (170 kg); Single hook; red.
AC 100/4 ( L )
