Functional
Description
Optimal working with
the measuring tool is
possible
the operating instruc-
tions and information
are read completely,
and the instructions contained
therein are strictly followed. SAVE
THESE INSTRUCTIONS.
Please unfold the fold-out page with
the representation of the measuring
tool and leave it unfolded while reading
the operating instructions.

Intended Use

The measuring tool is intended for
quick and precise measurement of
inclinations and angles.

Product Features

The numbering of the product features
shown refers to the illustration of the
measuring tool on the graphic page.
1 Battery lid
2 Spirit level for horizontal alignment
3 Spirit level for vertical alignment
4 Closing cap
5 Protective case
6 Display
7 "ON/OFF" button
8 Acoustic signal button
9 "Calibrate" function button
10 "° % mm/m" button for changing
the unit of measure
11 "HOLD/COPY" button
Display Elements
a Alignment aides
b Reading
c Acoustic signal
d Battery indication
e Units of measure: °; %; mm/m
