Fault Localisation, Troubleshooting

CAUTION
Remediation of any of the faults
described below may only be
carried out by a trained technician.
Fault Possible cause
No compressed air available.
Pump pressure control valve
(Figure F/no. 13) adjusted incor-
Pumpe startet nicht.
rectly.
Empty message limit switch
(Figure I/no. 19) activated (option).
Leak or kinked lines.
Pressure on the follower piston
Pump doesn't apply any or too plate is too low (Figure E/ No. 11).
low of a pressure.
Air pressure too low.

Maintenance

The indicated maintenance intervals are based on
single-shift operation. Depending on the use site,
medium and cases of multi-shift operation, main-
tenance may need to be performed more frequently.
WHEN WHAT HOW WHO
During every Check for visual Operating
drum damage to company
changeover the follower technicians
plate
Weekly Check visual Operating
hoses and company
fittings for technicians
leaks
CAUTION
All work on the plant absolutely must
be done when it is idle. The
pneumatic and hydraulic systems
must be de-pressurised. The
manometers must show 0 bar.
24
Corrective action
Check the compressed air supply and
shut-off valve (Figure F/No. 12+14).
Set the pressure control valve to a
higher pressure (increase)
(Figure F/no. 13).
Use a full container.
Inspect the hoses and fittings.
Carefully increase the pressure
using the pressure control valve on
the follower piston plate
(Figure F/No. 15).
Have the compressed air supply
checked.

Customer Service / Support

ABNOX AG
Langackerstrasse 25
CH-6330 Cham
Switzerland
Tel. +41 (0) 41 780 44 55
Fax +41 (0) 41 780 44 50
E-Mail info@abnox.com
Internet www.abnox.com

De-Commissioning

Brief Interruptions:
In the event of short interruptions (overnight or just
over the weekend), shut down the product. The
system must be de-pressurised.
Long-Term Interruptions:
In the event of a longer-term interruption (more than
three days), the following points should be observed:
• The main switch must be shut down
• The system must be de-pressurised (check the
displays)
CAUTION
Risk of accident and danger to the
environment:
Grease / oil on the ground increase
the risk of accident.
The grease/oil must be properly
disposed of in compliance with
applicable national ordinances
(hazardous waste).

Drawings and Replacement Parts

Accessories, drawings, dimensioning sheets, data
sheets and replacement parts can be found at
www.abnox.com.

Expansion options

Casters LR option
The casters (Figure G/No. 16) are an ideal option in
order to be able to quickly and flexibly transport the
drum pump from one place to another.
DANGER
Only move in the retracted state
and solely on level surfaces.
Feet SF option
The feet (Figure G/No. 17) provide an excellent trans-
port option using a lift truck.
DANGER
Only move in the retracted state
and solely on level surfaces.
Connection block with bleeder AB
Displays the outlet pressure and provides a simple
bleeding method (Figure H/No. 18).
Audible empty signal L
When the fill level is low, the limit switch (Figure I/
no. 19) interrupts the pump air supply and an audible
signal sounds. The volume control (figure I/no. 21)
can be used to adjust the volume of the signal. The
signal is turned off by turning the system off
(Figure F/no. 14).

Idling and Disposal

When de-commissioning/idling the product, please
heed the following points:
• Switch off the main switch (if any)
• Unplug the main power plug from the main supply
(if any)
• The system must be depressurised.
• The medium must be removed and properly
disposed of.
ENVIRONMENTAL HAZARD
The various materials /liquids must
be properly and separately handled
and disposed of in compliance with
the applicable national ordinances.
Lubricants are considered
hazardous waste.
© Publisher's Copyright
This document may only be reproduced, translated
or made accessible to third parties with the expres-
sed consent of the publisher.

Re-Sale

This Operating Manual is a component of the product
and belongs in the scope of delivery in the event of
re-sale.
