REF PART # DESCRIPTION
1 606146 DFILTER, SCREEN, SOL- -FILL
2 140032 WASHER #6 FLT SS
3 140826 DSCREW, PAN, #06- -32 X 0.75, PHL
SS SHTMTL
4 605062 DGASKET, COVER, SOLUTON FILL
5 605061 DCOVER SOLUTION FILL
6 578301 DKNOB, RND, .D. L10- -32
7 621443 DCHAIN, BALL, #10 X 157L, SS
8 07514 WASHER, LOCK, INT, #10, SS
9 578201000 SCREW, PAN, #10- -32 X 0.50,
PHL, ZN
10 606697 CLAMP, CABLE, STL, 1.12D X
0.50W, 1H, VYL
11 140000 WASHER, FLAT, 0.28B 0.62D .04
12 578244000 WASHER M6.4X10 LCK SS
13 608322 SCREW, TRS, M6 X 1.0 X 16,
PHL, SS
14 608322 SCREW, TRS, M6 X 1.0 X 16,
PHL, SS
15 578244000 WASHER M6.4X10 LCK SS
16 140000 WASHER, FLAT, 0.28B 0.62D .04
17 605244 HINGE, .25PIN .07 2.0W 22.0L,
YLW ZN
18 608322 SCREW, TRS, M6 X 1.0 X 16,
PHL, SS
19 578244000 WASHER M6.4X10 LCK SS
20 140000 WASHER, FLAT, 0.28B 0.62D .04
21 140960 CABLE, .13D, 14.5L,
.343EYE/.343EYE
∇ ASSEMBLY / CONJUNTO
INCLUDED IN ASSEMBLY / INCLUIDO EN EL CONJUNTO
Y
D RECOMMENDED STOCK ITEMS / ARTICULOS RECOMENDADOS PARA
MANTENER EN EXISTENCIA
Nobles Strivet (11- -04)
SOLUTION TANK GROUP
GRUPO DEL TANQUE DE SOLUCION
QTY.
1
2
2
1
1
1
1
1
1
3
3
3
3
9
9
9
1
2
2
2
1
Home Find... Go To..
REF PART # DESCRIPTION
22 613971 TRAY, BATTERY, (RM- -CO)
23 1017387 TANK, SOLUTION, RM- -SPGN
(RM- -CO)
24 605394 FITTING, BRS, E45, PM04/BM06, T
25 607775 CLAMP, HOSE, WIRE, .63- -.66, BLK
26 606879 HOSE SIGHT GAGE
27 150419 FITTING, BRS, E90, PM04/BM06, T
28 1012965 CAP, PORT, SOLUTION FILL
29 140340 SCREW, PAN, #10- -24X0.62, SS,
TYP 25
30 01683 WASHER, FLAT, #10 SS
31 608322 SCREW, TRS, M6 X 1.0 X 16,
PHL, SS
32 578244000 WASHER M6.4X10 LCK SS
33 140000 WASHER, FLAT, 0.28B 0.62D .04
34 601460 CLIP, HANGER, HOSE, .25D HOLE,
CLR ZN
∇ 35 1010143 DHOSE, DRAIN ASSEMBLY 31.2"
1008639 DCAP, DRAIN ASSEMBLY
∇36
Y
37 1019563 DSTRAP, DRAIN CAP
Y
38 1008637 DO- -RING, 1.48"ID X 1.76"OD
Y
39 614157 CLAMP, HOSE, WORMDRIVE
1.06- -2.00D, .50W
40 603012 DKNOB, RND, 19D PLSTC, M6X12
STUD - -ZN
41 1011890 SHROUD, SCRUB HEAD
42 606521 DECAL, GENERAL HAZARD
44 1018849 LABEL, WAND
PARTS LIST
LISTA DE PIEZAS
QTY.
1
1
1
1
1
1
1
1
1
2
2
2
2
1
1
1
1
1
5
1
1
1
