REF PART # DESCRIPTION
1 377500 DBELT, SYNCHRONOUS, 15MM
05P 500L
2 1006713 DSPROCKET, CAST, 48 TOOTH, 5P
3 00911 KEY, SQ, 0.19 X 0.19, 0.75L
4 08712 NUT, HEX, LOCK, M6 X 1.0, SS, NL
5 363503 SCREW, PAN, M6 X 1.0 X 12, SS
6 378805 PLUG, DRIVE, BRUSH, MACH
7 01684 WASHER, FLAT, 0.25 SS
8 200655017 WASHER, M6.1 LCK SS DIN127
9 15678 SCREW, HEX, M6 X 1.0 X 16, SS
10 41360 DBEARING, BALL, 0.59B 1.26D
0.35W [2SEAL]
11 1002077 SPACER, 0.594B X 0.81D X 0.5L
12 1001792 HOUSING, BRG
13 76490 ROD, THRD, 2 END, M08X1.3 08.2L
14 08713 NUT, HEX, LOCK, M8 X 1.25, NL, SS
15 1017216 DMOTOR .7HP 750RPM 24VDC 14A
16 630447 WASHER, FLAT, M12.7 X 25.4 X 0.8
NY
17 375195 DSPROCKET, TIMING, 22TOOTH,
0.50B
18 222818 SCREW, SET, #08- -32 X 0.25, NL
19 140027 WASHER, FLAT, 0.35B 0.75D .04
20 606795 HARNESS MOTOR CYL- -BRUSH
D RECOMMENDED STOCK ITEMS / ARTICULOS RECOMENDADOS PARA
MANTENER EN EXISTENCIA
Nobles Strivet (11- -04)
SCRUB HEAD GROUP
GRUPO DEL CABEZAL LIMPIEZA
QTY.
2
2
2
8
8
2
2
2
2
4
2
2
2
4
2
2
2
4
4
2
Home Find... Go To..
REF PART # DESCRIPTION
21 200370019 WASHER, LOCK, M8.4 ZN D6797
22 07786 NUT, HEX, STD, M8 X 1.25, SS
23 608964 BOOT TERMINAL BLACK
24 608963 BOOT TERMINAL RED
25 379202 DPLUG, IDLER BRUSH SGL BRNG
26 01516 RING, RETAINING, EXT, 0.59D
27 222177 SHAFT, IDLER PLUG
28 222184 PIN, ROLL, .094 D X 0.25L, .094/.097
29 1011197 DOOR, ROLLER
30 32485 WASHER, FLAT, 0.38 SAE
31 140022 WASHER, INT 3/8 SS
32 140276 SCREW, HEX, M10 X 1.5 X 16, SS
33 1017420 HOUSING WLDT
34 1002078 SPACER, .50X X 1.25L, M6 THREAD
35 1008675 DGASKET, FOAM, EDGE
36 630453 DGASKET, 143MM, FR CONSOLE,
PANEL
37 1012951 DCOVER, BELT, (RM- -CO)
38 140000 WASHER, FLAT, 0.28B 0.62D .04
39 363503 SCREW, PAN, M6 X 1.0 X 12, SS
40 140000 WASHER, FLAT, 0.28B 0.62D .04
41 07515 WASHER, LOCK, INT, .25, SS
42 15678 SCREW, HEX, M6 X 1.0 X 16, SS
PARTS LIST
LISTA DE PIEZAS
QTY.
4
4
2
2
2
2
2
2
2
2
2
2
1
4
2
2
2
4
4
4
4
4
