REF PART # DESCRIPTION
1 1013300 DGUAGE, PRESS, BRUSH
2 602919 DSWITCH, ROCKER, VDC DPDT
ON/ON
3 1007012 DSWITCH, ROCKER, 125VDC 16A
DPDT MO/OF/MO
4 130738 DLIGHT, INDICATOR, VDC, GREEN
5 603076 DGUAGE, DISCHARGE, BATTERY,
24VDC DIGITAL
6 630265 DKNOB, RND, 0.75D X 0.50L X
0.25B PLSTC
7 1013306 LABEL, MAIN DASH
8 1012689 PANEL, CONSOLE
9 200301014 WASHER M4.3X10.1X1 FLT ZN
10 02938 WASHER, LOCK, INT, 08, SS
11 200070340 SCREW, PAN, M4 X 0.7 X 8, PHL
12 130761 DBOOT BREAKER - - CLEAR SILI-
CONE
13 1013304 LABEL, CIRCUIT BREAKERS
14 130785 DSWITCH, KEY, 150VAC 16A
607821 DKEY REPLACEMENT STEEL
15 604793 DECAL, KEYSWITCH ON(1)/OFF(0)
16 630119 GASKET, CONSOLE 3.1X8.0X420
D RECOMMENDED STOCK ITEMS / ARTICULOS RECOMENDADOS PARA
MANTENER EN EXISTENCIA
Nobles Strivet (11- -04)
COMPONENT PANEL GROUP
GRUPO DEL PANEL DE COMPONENTES
QTY.
1
1
1
1
1
1
1
1
4
4
4
2
1
1
1
1
2
Home Find... Go To..
REF PART # DESCRIPTION
17 1009324 SCREW, PAN, #10- -16 X 0.50, PHL,
TY- -17 BLK
18 603008 DRELAY, 24VDC, 100A, SP N/O
[TROMBETT]
19 606404 DDIODE, ASSY W/RING
TERMINALS
20 1007108 NUT, HEX, LOCK, M6 X 1.0, KEP
EXT
21 630453 GASKET, 143MM, FR CONSOLE,
PANEL
22 1013270 DRELAY, 24VDC, 2PDT, 20AMP
23 1007109 NUT, HEX, LOCK, M4 X 0.7, KEP
EXT
24 1006477 DCIRCUIT BREAKER 17 AMP
25 607394 DDIODE, .25 PIGGYBACK TERM
26 383723 DCIRCUITBREAKER, 20A,
RESETABLE
27 383721 DCIRCUITBREAKER, 10.0A
28 603314 DRELAY ASM, LOW VOLTAGE IN-
TERPT
29 606727 CLAMP, CABLE, STL, 0.62D X .38W,
1H VYL
30 613682 DPOTENTIOMETER, 0- -20K,
SPEED C
PARTS LIST
LISTA DE PIEZAS
QTY.
4
1
1
2
2
1
3
2
1
1
1
1
1
1
