Safety is no longer guaranteed e.g. in the following cases:
- obvious damage
- broken housing, cracks in housing
- if the tester can no longer perform the required measurements/
tests
- stored for too long in unfavourable conditions
- damaged during transport
- leaking batteries
The tester complies with all EMC regulations. Nevertheless it can
happen in rare cases that electric devices are disturbed by the
electrical field of the tester or the tester is disturbed by electrical
devices.
Never use the tester in explosive environment
Tester must be operated by trained users only
Operational safety is no longer guaranteed if the tester is modi-
fied or altered.
The tester may be opened by an authorized service technician
only.
5.1

Intended Use

The tester may be used only under the conditions and for the
purposes for which it was designed. Therefore, observe in particular
the safety instructions, the technical data including environmental
conditions.
6

Testers Information

6.1

Device elements EazyVolt Pro LED

1. Test probe, L1 (-)
2. Torchlight button
3. LED indication
4. Test tip, L2 (+)
6.2

Display elements EazyVolt Pro LED

1. Single pole test; ELV warning
2. Voltage indication
3. LEDs indicating 6 V and polarity
4. Rotary field - L(left) and R(right)
5. Buzzer/continuity LED (when blinking indicates low battery)
6.3 Device elements EazyVolt Pro LCD
1. Test probe, L1 (-)
2. RCD button
3. Torchlight/function button (function sequence: Voltage/Con-
tinuity  Low voltage  Diode test  Resistance  Frequency 
NCV)
4. RCD button
5. LCD with backlight
6. Test tip, L2 (+)Test probe, L1 (-)
7. Torchlight button
8. LED indication
9. Test tip, L2 (+)
6.4

Display elements EazyVolt Pro LCD

1. Single pole test; ELV warning
2. Voltage indication
3. LEDs indicating 6 V and polarity
4. Rotary field - L(left) and R(right)
5. Buzzer/continuity LED (when blinking indicates low battery)
7

Preparation for tests

7.1 Auto-power-on/ switching on
• The tester switches on when it detects shorten tips, or an AC
or DC voltage above approx. 10 V or a live phase on + (single
pole test)
• It can be switched on with the
7.2 Auto-power off
• Tester is automatically powered off after approx.10 sec when
there is no signal contacted to the probes
6
www.nieaf-smitt.com
button
