2. How to adjust the width of this product
①Tighten upper Adjuster Knobs until the rubber of the Adjuster Bolts touch the wall.
②Tighten upper Adjuster Knobs until the clearance between the product and wall is the same on both sides
(as shown in Figure 1).
③Tighten lower Adjuster Knob to make sure the product vertical, and stretch the product fully (as shown in Figure 2).
Turn each Adjuster Knob
in the direction of arrows
Warnings!
l Make sure to tighten Adjuster Knob equally on both sides
to prevent overturning or damage to the product.
Installation Check
If correctly installed, the product should not feel loose or
wobbly when tugged. This product should be attached to
the wall securely and safely to ensure pet safety and
prevent damage to product/wall.
How to Disassemble
Rotate Adjsuter Knobs in the opposite direction from assembling to loosen and remove.
Cautions!
l Be careful not to drop the product during disassembly.
<Use as freestanding pet gate>
How to assemble
1. Attach Side Panel
①Attach the Panel with Door and Side Panel using Fixing Bolts
as shown on right Figure.
②Then, attach Adjuster Panel and other Side Panel using Fixing Bolts
as shown on right Figure.
2. How to screw Fixing Bolt
The position of Fixing Bolt depend on the desired gate width.
(See on page 2)
Settled width and the position of Fixing Bolts
①Align Adjustment holes and Fixing holes according to desired width
(Width of gate can be adjusted by intervals of approx. 1.3".)
②Attach the Panel with Door and Adjuster Panel with Fixing Bolts. Make
sure to insert Fixing Bolts on top and bottom (2 positions) of each Panel
using Phillips-head screwdriver.
Flat Washer
Spring Washer
Fixing Bolt
※Remove the zip tie on Pet Door before assembling. Then, determine the direction of the door opening/closing.
※Use a Phillips-head screwdriver for assembly.
How to screw Fixing Bolt
Figure 1
Make sure to adjust the space between the product and wall is
safe width that pets can not escape or getting pinched.
Figure2
90 degrees
Cautions!
l Install the product against the wall vertically.
l The bottom of the product must contact the floor.
Adjustment hole
Fixing hole
3
90 degrees
Wider than 2.4"
Less than 2.4"
Fixing hole
Adjustment hole
Flat
Washer
Fixing Bolt
Spring
Washer
