Thicker than RG-6U (5C-2V): 500 m / 547 yds. max.
(Non-PoE power supply)

Power Supply Connection

To prevent a fire hazard use any UL
listed wire rated VW-1.
GND GND
~ ~
~ ~
Check that +/- polarity is correct.
– –
+ +
✱2 Thicker than 18 AWG
Switching hub
Shielded LAN cable
& "Connection when Using PoE (Power
over Ethernet) Power Supply" (P8).
& "Connection when Not Using PoE
(Power over Ethernet) Power Supply"
(P9).
AC 24V
DC 12V
Monitor Connection
Using different cables from those
specified here may attenuate the
video and/or sync signals and
interfere with correct transmission.

LAN Connection

PC
PC
12
PC
