Valeurs maximales de bruit et de vibrations
Pour le modèle................................................................ (1) (2) (3) (4) (5) (6)
Niveau de pression acoustique à l'oreille de l'opérateur
(en référence à la norme 81/1051/CEE) ........................ db(A) 80,6 78,5 81,6 83,7 83,4 81,8
- Incertitude de la mesure (2006/42/CE - EN 27574) .. db(A) 0,5 0,9 0,9 0,2 1,0 0,2
Niveau de puissance acoustique mesuré (en
référence à la directive 2000/14/CE, 2005/88/CE)........ db(A) 95,7 91,8 94,5 97,3 96,5 95,4
- Incertitude de la mesure (2006/42/CE - EN 27574).... db(A) 0,2 0,8 0,3 0,3 0,1 0,2
Niveau de puissance acoustique garanti (en
référence à la directive 2000/14/CE, 2005/88/CE)........ db(A) 96 96 96 98 98 98
Niveau de vibrations (en référence à la norme EN 1033) .. m/s
- Incertitude de la mesure (2006/42/CE - EN 12096) .... m/s
EN
IDENTIFICATION LABEL AND MACHINE COMPONENTS
1.
Acoustic power level according to directive 2000/14/EC
2.
Conformity mark according to directive 2006/42/EC
3.
Year of manufacture
4.
Type of lawnmower
5.
Serial number
6.
Name and address of Manufacturer
7.
Article Code
8.
Engine power and speed
9.
Mass in kilograms
As soon as you have purchased the machine, do not forget to write
the identification numbers (3 - 4 - 5) in the spaces on the last page
of the manual.
11. Chassis 12. Engine 13. Blade (Blade) 14. Stone-guard
15. Grass-catcher 16. Handle 17. Throttle trigger 18. Engine
brake lever 19. Drive engagement lever
DESCRIPTION OF SYMBOLS ON CONTROLS
(where applicable)
21. Slow 22. Fast 23. Choke
24. Engine stop 25. Drive on
26. Idle 27. Engine ignition
30. Rear discharge 31. "Mulching" or side discharge
36. Grass-catcher contents indicator: lifted (a) = empty / lowered
(b) = full
SAFETY REQUIREMENTS - Your lawnmower should be used with
due care and attention. Symbols have therefore been placed on
various parts of the machine to remind you of the main precautions
to be taken. Their meaning is explained below. You are also asked
to carefully read the safety regulations in the applicable chapter of
this handbook.
41. Warning: Read the instruction manual before using the
machine.
42. Beware of thrown objects. Keep other people at a safe dis-
tance whilst working.
43. Danger of cutting yourself. Moving blades. Do not put
hands or feet near or under the opening of the cutting plate.
Disconnect the spark plug cap and read the instructions befo-
re carrying out any maintenance or repairs.
Maximum noise and vibration levels
For model ...................................................................... (1) (2) (3) (4) (5) (6)
Operator ear noise pressure level (according to
regulation 81/1051/EEC) ............................................... db(A) 80,6 78,5 81,6 83,7 83,4 81,8
- Measurement uncertainty (2006/42/EC - EN 27574).. db(A) 0,5 0,9 0,9 0,2 1,0 0,2
Measured acoustic output level (according to
directive 2000/14/EC, 2005/88/EC)............................... db(A) 95,7 91,8 94,5 97,3 96,5 95,4
- Measurement uncertainty (2006/42/EC - EN 27574).. db(A) 0,2 0,8 0,3 0,3 0,1 0,2
Guaranteed acoustic output level (according to
directive 2000/14/EC, 2005/88/EC)............................... db(A) 96 96 96 98 98 98
Vibration level (according to the standard EN 1033) ..... m/s
- Measurement uncertainty (2006/42/EC - EN 12096) ... m/s
2
7,11 3,94 6,68 5,61 3,7 3,3
2
0,5 0,9 0,3 0,4 0,4 0,3
2
7,11 3,94 6,68 5,61 3,7 3,3
2
0,5 0,9 0,3 0,4 0,4 0,3
DE
KENNUNGSSCHILD UND MASCHINENBAUTEILE
1.
Schalleistungspegel gemäß Richtlinie 2000/14/EG
2.
Konformitätszeichen (CE) nach der Richtlinie 2006/42/EG
3.
Herstellungsjahr
4.
Typ des Rasenmähers
5.
Seriennummer
6.
Name und Anschrift des Herstellers
7.
Artikelnummer
8.
Motorleistung und Drehzahl
9.
Gewicht in kg
Tragen Sie sofort nach dem Kauf der Maschine die Kennnummern
(3 - 4 - 5) in die entsprechenden Felder auf der letzten Seite des
Handbuchs ein.
11. Chassis 12. Motor 13. Messer 14. Prallblech 15.
Auffangsack
16. Handgriff 17. Gasbetätigung 18. Bremshebel des Motors
19. Hebel Einkuppeln Antrieb
BESCHREIBUNG DER SYMBOLE AN DEN BEDIENELEMEN-
TEN
(wo vorgesehen)
21. Langsam 22. Schnell 23. Choke
24. Motor Stillstand 25. Antrieb eingeschaltet
26. Pause 27. Motor starten
30. Hinterer Auswurf 31. "Mulching" oder seitlicher Auswurf
36. Anzeiger Sackinhalt: angehoben (a) = leer / abgesenkt (b) =
voll
SICHERHEITSVORSCHRIFTEN - Bitte
Benutzung Ihres Rasenmähers vorsichtig. Hierfür wurden an der
Maschine Piktogramme angebracht, die Sie an die wichtigsten
Vorsichtsmaßnahmen für die Verwendung erinnern sollen. Die
Bedeutung der Symbole wird im folgenden erklärt. Lesen Sie außer-
dem aufmerksam die Sicherheitsvorschriften durch, die im entspre-
chenden Kapitel des vorliegenden Handbuchs aufgeführt sind.
41. Achtung: Vor dem Gebrauch der Maschine die
Bedienungsanleitung lesen.
42. Auswurfgefahr. Personen während des Betriebs vom
Arbeitsbereich fernhalten.
43. Schnittgefahr. Messer in Bewegung. Bringen Sie nie Hände
oder Füße in die Öffnung unter dem Mähwerk. Stecken Sie
den Zündkerzenstecker ab und lesen Sie vor allen Wartungs-
oder Reparaturarbeiten die Anweisungen durch.
Maximale Geräusch- und Vibrationswerte
Für Modell ...................................................................... (1) (2) (3) (4) (5) (6)
Gewichteter Schalldruck am Ohr des Bedieners
(gemäß der Norm 81/1051/EWG).................................. db(A) 80,6 78,5 81,6 83,7 83,4 81,8
- Messungenauigkeit (2006/42/EG - EN 27574) .......... db(A) 0,5 0,9 0,9 0,2 1,0 0,2
Gemessener Schallleistungspegel (gemäß
Richtlinie 2000/14/EG, 2005/88/EG) ............................. db(A) 95,7 91,8 94,5 97,3 96,5 95,4
- Messungenauigkeit (2006/42/EG - EN 27574) ........... db(A) 0,2 0,8 0,3 0,3 0,1 0,2
Garantierter Schallleistungspegel (gemäß Richtlinie
2000/14/EG, 2005/88/EG) ............................................. db(A) 96 96 96 98 98 98
Gewichteter Vibrationspegel (gemäß der Norm EN 1033) .. m/s
- Messungenauigkeit (2006/42/EG - EN 12096) ............ m/s
[1] = DM 504
[2] = DM 504 (AVS)
[3] = DML 504
[4] = DM 554
[5] = DML 554
[6] = DML 554 (AVS)
seien
Sie
bei
der
2
7,11 3,94 6,68 5,61 3,7 3,3
2
0,5 0,9 0,3 0,4 0,4 0,3
7
