Wiring the GRAFIK Eye

QS Link Control Wiring Details

• System communication uses IEC PELV/NEC
Class 2 wiring.
• Follow all local and national electrical codes when
installing IEC PELV/NEC
®
voltage/mains wiring.
• Each terminal accepts up to two 18 AWG (1.0 mm
wires.
• Total length of control link must not exceed
2000 ft (610 m).
• Make all connections in the control unit's wallbox.
• Wiring can be T-tapped or daisy-chained.
• IEC PELV/NEC Class 2 24 V
®
System Limits
The QS wired communication link is limited to 100
devices or 100 zones.
The GRAFIK Eye QS control unit supplies 3 Power
®
Draw Units (PDUs) on the QS link. Refer to the
QS Link Power Draw Units specification submittal
(Lutron PN 369405) for more information concerning
Power Draw Units.
Wire Sizes (check compatibility in your area)
QS Link Wiring Length
Less than 500 ft (153 m)
500 to 2 000 ft
(153 to 610 m)
®
QS Control Unit:
®
®
Class 2 wiring with line
)
2
150 mA.
Wire Gauge
Power (terminals 1 and 2)
1 pair 18 AWG (1.0 mm )
2
Data (terminals 3 and 4)
1 twisted, shielded pair 22 AWG (0.5 mm
Power (terminals 1 and 2)
1 pair 12 AWG (4.0 mm )
2
Data (terminals 3 and 4)
1 twisted, shielded pair 22 AWG (0.5 mm
For additional information, see the complete installation and operation guide at www.lutron.com/qs
LUTRON LUTRON
T-Tap Wiring Example
GRAFIK Eye
®
control unit
QS smart
power
panel
Sivoia QS
®
shade/drape
Daisy-Chain Wiring Example
GRAFIK Eye QS
®
control unit
LUTRON LUTRON
Lutron Cable Part Number
GRX-CBL-346S (non-plenum)
GRX-PCBL-346S (plenum)
)
2
GRX-CBL-46L (non-plenum)
GRX-PCBL-46L (plenum)
)
2
GRAFIK Eye QS Control Unit Quick Installation and Operation Guide 7
®
LUTRON LUTRON LUTRON
LUTRON
seeTouch QS
QS
®
wallstation
LUTRON
LUTRON
LUTRON
LUTRON
LUTRON
Sivoia
®
GRAFIK Eye QS
QS
®
control unit
shade/
drape
LUTRON
LUTRON
QS smart
power panel
LUTRON
LUTRON
LUTRON
LUTRON
LUTRON
seeTouch QS
®
wallstations
