Zone Setup (continued)

Setting Load Types

Fixture load type
Incandescent
MLV (magnetic low-voltage)
ELV (electronic low-voltage)
Hi-Lume /Eco-10
®
®
0-10 V
Non-dim lighting loads
Neon/Cold cathode
Tu-Wire
®
Advance Mark X
®
DMX
RGB/CMY DMX
Cree LR4/LR6 LED
®
Direct control via
GRAFIK Eye QS
®
control unit
LUTRON
Choose this load type from the menu
on the GRAFIK Eye
Incandescent
LUTRON
MLV
—
—
—
Non-dim
Neon, CC
Tu-Wire
Tu-Wire
—
—
Cree LR4/LR6 LED
For additional information, see the complete installation and operation guide at www.lutron.com/qs
GRAFIK Eye
Control via
power module or
interface
Power
module or
LUTRON
interface
LUTRON
QS control unit:
®
Power module
Power module
Power module
Fluorescent module
Fluorescent module
Non-dim
Neon, CC
Tu-Wire
Tu-Wire
DMX
RGB/CMY DMX
Fluorescent module
QS Control Unit Quick Installation and Operation Guide 13
®
Load Type Notes
• All electronic low-voltage
(ELV) lighting used with an
interface must be rated for reverse
phase control dimming. Before
installing an ELV light source,
verify with the manufacturer that
their transformer can be dimmed.
When dimming, an ELV interface
(such as the PHPM-PA-DV-WH)
must be used with the control
unit.
• For all DMX or RGB/CMY DMX
lighting, an external DMX interface
(such as the QSE-CI-DMX) must
be used with the control unit.
• Maximum total lighting load for
Lutron Tu-Wire and Advance
® ®
Mark X electronic dimming
®
ballasts (120 to 127 V only)
must not exceed 6 A per zone or
16 A per unit.
Zone ratings:
• Not all zones must be connected;
however, connected zones must
have a minimum load:
120 - 127 V : 25 W
220 - 240 V : 40 W
• Maximum zone loads:
120 - 127 V : 800 W
220 - 240 V : 1200 W
• Maximum total lighting load for
magnetic low-voltage (MLV) varies
by input voltage:
120 - 127 V : 800 VA / 600 W
220 - 240 V : 1200 VA / 960 W
