SETUP AND OPERATING OPTIONS

General setup diagram

Meanings of the various parameters

Programming example: adjusting the long slowdown zone "P1=3" (Fig. 24)
Code Désignation
Obstacle detection sensitivity
P0
Closure approach speed
P1
Memorising the remote control for controlling lighting

Memorising a Telis or similar type remote control

SPECIAL OPERATION

Refer to the User's Manual.

CLEARING REMOTE CONTROLS AND ALL SETTINGS

Clearing remote controls

Press the "PROG" button until the light blinks (7 s).
This clears all of the remote controls memorised.

Resetting all settings

Press the "SET" button until the light goes out (7 s).
This clears all previously stored settings and returns them to their default values.

LOCKING PROGRAMMING

Used to lock the programming settings (end limit setting, self-learning, setup).
Simultaneously press the "SET", "+" and "-" buttons:
- start by pressing "SET".
- pressing "+" and "-" must take place within two seconds.
Pressing the "SET" button then no longer has any effect.
The remote control memorising functions ("PROG" button) and forced mode operation ("+", "-" buttons) remain possible.
To access programming mode once again, repeat the same procedure.

REFITTING COVERS

Position the aerial and fi t the covers.
To ensure proper remote control range, the aerial must be fi tted in one of the two positions shown in Figure 30.
Fig. 23
Valeurs
1 : low sensitivity
2 : low sensitivity
3 : standard
4 : high sensitivity
1 : no slowdown
2 : short soft stop
3 : long soft stop
Fig. 27
Fig. 28
(Fig. 29)
(Fig. 30)
Commentaires
If this setting is changed, it is essential to run the force measurement
sequence at the end of the installation procedure
P1=1: no slowdown before closure.
P1=2: speed is reduced during the last 20 centimetres.
P1=3: speed is reduced during the last 50 centimetres.
If this setting is changed, it is essential to run the force measurement
sequence at the end of the installation procedure.
Fig. 25
Fig. 26
7
