Cleaning - Robot Coupe MP 350 Turbo Manual De Instruccion

- Repeat this procedure with the second whisk. If
you cannot push it in properly, remove it, rotate it
90° and start again.
Removing the whisk from the whisk holder
While griping the
B
ejector A in one
hand and the holder
in the other, pull
B
the ejector in the
direction of the
arrow.
Removing the ejector
Hold the whisk by the
B
wires
With the other hand, pull
B the ejector
direction of the arrow
(see figure).
A
W A R N I N G
• Always unplug the power mixer before
cleaning it!
• Always dilute bleach according to the
instructions on the label
• Never run the motor assembly through a
dish machine.
• The type and concentration of the sanitation
agent must comply with 21 CFR 178 1010
regulations.
• Clean according to local health department
regulations.
• CLEANING THE MOTOR HOUSING
The power mixer must be clean through all stages
of production. Clean between each job using a
detergent or disinfectant. Dilute the detergent /
disinfectant following the instructions normally
specified on it's packaging container. Use a cloth
lightly dampened (not dripping) with the cleaning
solution.
Do not allow liquid to come into contact with the
electrical components contained within the
housing. Be careful when cleaning around vents
do not allow liquid to drip or seep into
the housing. Use a cloth lightly dampened
A
(not dripping) with water to remove detergent /
disinfectant then dry using a clean cloth.
After using the power mixer in a hot mixture,
cool the bottom of the tube in cold water before
disassembling the bell from the tube.
in one hand.
Clean immediately after use to prevent product from
sticking to surfaces.
A in the
W A R N I N G
Never immerse motor housing and/or handle
in liquid! The housing contains the electrical
components and is not sealed against liquid.

CLEANING

Contact with liquid can cause damage to the
blender and serious injury to the operator.
• CLEANING THE TUBE AND BELL
There are two ways to proceed :
• Simple cleaning procedure after each different use
- Submerge the tube and bell in water and run for a
few seconds to clean.
- Unplug the power cord.
Complete cleaning procedure on a daily basis
- Unplug the power mixer and rinse the bell under a
water tap.
- Remove the bell from the tube, then remove the
blade (wear cutting gloves) ! Be careful to avoid
damaging the surface of the blade shaft and the
watertight seals.
- Always dilute the detergent/disinfectant (see
above).
- Thoroughly dry all parts before reassembling.
• BLADE
The blade can be removed from the bell for
thorough cleaning.
Always dry thoroughly to avoid spotting.
• ALUMINUM
Use soft-metal-safe cleaning agents!
• PLASTIC
Be careful, many cleaning agents are corrosive and
are not safe for use on plastics!
Do not use strong alkaline detergent (having a high
concentration of soda or ammonia).
• WHISK HOLDER
Never immerse the whisk holder in water. Clean it
with a cloth lightly dampened (not dripping).
Never run the whisk holder through a dishwasher.
• WHISKS
The whisks can be cleaned either by hand or in a
dishwasher.
To ensure effective cleaning, always remove the
whisk ejector.
MAINTENANCE
• BLADE
Over time the blades will become worn and will need
to be replaced. The washer and seals should also be
replaced at this time. A blade service kit is available.
9
