Ribbon save (continuous mode)

Keys: , , ,
Key:

Mode: Standard

Key:
Key:
Key:
Key:
Key:
Key:
Key:
Mode:
Selection of ribbon save mode.
Off: Ribbon save set to Off.
Standard: Maximum ribbon save performance
SaveStrt: No start signal loss
Speed: Determination of max. print speed.
Rewind correction:
0 mm = It is always so far retreated that an optimal ribbon save is reached.
Default: 0 mm
−xx mm = The retreat can be made smaller.
+xx mm = The retreat can be made larger.
Performance information:
sa/mm: The smallest possible distance of two prints with full ribbon save
cmin: Max. number of cycles per minute.
so/mm: Indicates the loss of ribbon save
ExpertParameters (password protected):
Enter password, press key
indicated:
PhDownT = printhead down time in ms:
Is used from ribbon save algorithm to use for the calculation of start time of printhead upward
movement.
REStartT = ribbon motor early start time in ms:
This value is added to the increase time of transfer ribbon movement.
MinSpeed = minimal print speed:
If the min. print speed is increased, the max. number of cycles is also increased.
Calcoff = Turn On/Off print offset border calculation:
If this parameter is set to Off, then a smaller as the required print offset can be entered.
PHupT = printhead up time in ms:
Is used from ribbon save algorithm to calculate if a field ribbon save can be made or not.
PhVReactT = valve reaction time in ms:
The time is calculated when to start with printhead upward movement.
RibMotStpDlayT = ribbon motor stop delay time
Decelaration time in ms in which the transfer ribbon motor is still moved with constant speed
before stopping.
FieldRS = field ribbon saving:
Off: Field ribbon save switched off.
Normal: Field ribbon save is only accomplished if the transfer ribbon motor can be completely
stopped.
PHOnly: Only the printhead is moved. The transfer ribbon does not stop.
Strong: Field ribbon save is even accomplished if the transfer ribbon motor cannot be
stopped.
Rwind v = rewind speed in mm/s:
Indication of rewind in mm/s.
English
to confirm the entry and the following parameters are
