Clean sieve in the water short-
age safe guard
Figure 9
Loosen covering nut and take off
hose.
Figure 10
Take out sieve.
Note
If necessary turn in screw M8 appr. 5
mm inwards and therewith pull out
sieve.
Clean sieve in water.
Push sieve inwards.
Put on hose.
Tighten covering nut firmly.
Clean filter at the detergent suck
hose
Figure 11
Take out detergent suck supports.
Clean filter in water and reinstall.
Oil change.
Figure 12
Ready a catch bin for appr. 1 Liter
oil.
loosen release screw.
Dispose of old oil ecologically or turn
in at a gathering point.
Tighten release screw.
Fill oil slowly up to the MAX marking.
Note
Air pockets must be able to leak out.
For oil type refer to technical specifi-
cations.
16
English
MALFUNCTIONS
Fuel indicator lamp glows
Figure 2 - Pos. 3
– Fuel tank empty
Refill.
Indicator lamp "Ready for use"
turns off
Figure 2 - Pos. 8
– Engine overload/overheat
Turn device switch on "0" and let en-
gine cool off for min. 5 minutes.
If malfunction still occurs, have de-
vice checked by customer service.
No line voltage, see "Appliance is
not running".
Figure 14
Check exhaust temperature limiter;
reduce it, if required.
Set the appliance switch to "I".
Indicator lamp liquid softener
glows
Figure 2 - Pos. 4
– Liquid softener tank is empty, due to
technical reasons a remainder stays
in the tank.
Refill.
– Electrodes in the tank are dirty
Clean the electrodes.
Engine control lamp glows
Figure 2 - Pos. 5
Set the appliance switch to "0".
Allow device to cool down.
Figure 14
Check exhaust temperature limiter;
reduce it, if required.
Set the appliance switch to "I".
