Operating data
a) measurement category according to IEC 61010-1 ...................... CAT IV 600 V (III 1000 V)
b) type of insulation ........................................................................................... double, Class II
c) housing type .............................................................................................. double-composite
d) degree of housing protection acc. to EN 60529 ............................................................. IP40
e) pollution degree .................................................................................................................... 2
f) power supply of the meter ...................................................................... 2x AA 1.5 V battery
g) indication for range exceeding .............................................................................OL symbol
h) low battery indication ...................................................................................... symbol
i) measurement rate ...................................................................3 measurements per second
j) INRUSH function
▪ sampling time .................................................................................................... 5 Hz (RMS)
▪ integration time................................................................................................................ 1 s
k) AC read-out ........................................................................................................... True RMS
l) AC bandwidth ...................................................................................................... 50...400 Hz
m) display ............................................................................................... 4 digit LCD with backlit
...................................................................................... 3000 counts with function indicators
n) dimensions ................................................................................................. 150 x 65 x 35 mm
o) flexible clamp dimensions ............................................................................... 140 x 180 mm
p) meter weight .................................................................................................................. 240 g
q) meter weight (without batteries) .................................................................................... 180 g
r) operating temperature ........................................................................................... +5..+40C
s) operating humidity ........................................................................................................ < 80%
t) storage temperature ............................................................................................. -20..+60C
u) storage humidity ........................................................................................................... < 80%
v) drop test ............................................................................................................................ 2 m
w) maximum operating altitude ....................................................................................... 2000 m
x) Auto-Off function ............................................................................................ approx. 15 min
y) compliance with the requirements of the following standards ............................EN 61010-1
........................................................................................ EN 61010-2-032, EN 61010-2-033
................................................................................................................................ EN 61326
z) quality standard ...................................................................................................... ISO 9001
Bluetooth specification
Version ............................................................................................................................ v4.0+EDR
Frequency range................................................................... 2400 MHz...2483.5 MHz (ISM band)
Guard band .................................................................................................... 2 MHz < f < 3.5 MHz
Modulation method ................................................................................ GFSK, 1 Mbps, 0.5 gauss
Receiving signal range ............................................................................................. -82...-20 dBm
Transmission power minimum................................................................................... -18...+4 dBm
