Basic Operation; Power; Select The Correct Tv System; Change System Menu Language - Soundstream H-540DiMT Manual De Instrucciones

Basic Operation

Power

You can use all the functions on the panel of the
unit or the remote control after connecting to power
supply (called Standby Mode).
Turning the System On
Press the button to turn the system on from
standby mode.
Note:
The set switches to the last selected source.
Turning the System Off
Press the button again to turn the system off
and go to standby mode.
Note:
Be sure to unplug the power cord from the outlet
when the system is not in use for an extended
period of time.

Select the Correct TV System

Change this setting if the video does not appear
correctly. By default, this setting matches the most
common setting for TV in your country.
1
No disc mode, press the SETUP button.
2
Select [Preference Setup Page].
3
Select [TV Type] and then press the
4
Select a setting and then press the ENTER
button.
- [PAL] - For TV with PAL color system.
- [Auto] - For TV that is compatible with both
NTSC and PAL (multi-system).
- [NTSC] - For TV with NTSC color system.
5
To exit the menu, press the SETUP button.

Change System Menu Language

1
Press the SETUP button.
2
Select [General Setup Page].
3
Select [OSD language] and then press the
button.
4
Select a setting and then press the ENTER
button.
5
To exit the menu, press the SETUP button .

Set the Clock

The built-in clock shows the correct time in the
display.
1
In standby mode, press and hold the CLOCK
button to activate the clock setting mode, hour
indicator will blink.
2
Set the hour with the
button.

button or button.
 
3
Press the ENTER or CLOCK button to confirm,
minute indicator will blink.
4
Set the minute with the
5
Press the ENTER or CLOCK button to confirm,
the built-in clock starts operating and the
seconds start counting from 0.
Note:
* The operating time of every step shouldn't be
longer than 10 seconds or it will return to the
original display.
* If there is a power failure or the power system is
turned off, the clock will lose its setting.
To confirm the clock time
When you press the CLOCK button, the clock time
is displayed. Wait for a few seconds until the display
returns to the original display.

Adjust Volume Level

During play, press the VOL+/- buttons to
increase/decrease the volume level.

Select a Preset Sound Effect

During play, press the EQ button repeatedly to
select:
- [POP]
- [CLASSIC]
- [ROCK]
- [JAZZ]
- [FLAT]

Super Bass Boost

Press the BASS button repeatedly to enable and
adjust bass level.

Mute Sound

During play, press the MUTE

sound. Press this button again or VOLUME+
button to cancel the effect.

Adjust Brightness of Display Panel

Press the DIM button repeatedly to select
different levels of brightness for the display
panel.
10
button or button.
 
button to mute
