Preference Page - Soundstream H-540DiMT Manual De Instrucciones

Gamma
This adjusts the gamma value of the picture.
Select High, Medium, Low or None using the
Cursor buttons, and press the ENTER button.
Hue
This adjusts the green/red balance of the picture
(only for progressive-scan and S-Video output).
Use the left and right buttons to change the
value, and press the ENTER button.
Saturation
This adjusts the saturation level.
Use the left and right buttons to change the
value, and press the ENTER button.
3
Press left button (

Page.
HDMI Setup
On (HDMI)
Select this to have the signal output when your
TV or monitor is connected to the HDMI out
terminal.
Off (HDMI)
Select this when you do not use the HDMI out
terminal.
No signal is output from the HDMI out terminal.
AUDIO FORMAT
AUTO
Detect and select the best supported audio format
automatically.
PCM
Multi-channel audio format will be down-mixed to
two channel sound.
RESOLUTION
The resolution options include Auto, 480i(60Hz),
4 8 0 p ( 6 0 H z ) , 7 2 0 p ( 6 0 H z ) , 1 0 8 0 i ( 6 0 H z ) ,
1 0 8 0 p ( 6 0 H z ) , 5 7 6 p ( 5 0 H z ) , 7 2 0 p ( 5 0 H z ) ,
1080i(50Hz) and 1080p(50Hz).
CEC SETUP
HDMI-CEC:
You can use one single remote control to control
all HDMI CEC devices that connected via HDMI
connection.
On
Enable HDMI-CEC feature
Off
Disable HDMI-CEC feature
One Touch Play:
When you press POWER button on RC to turn on
this player, the TV (if the TV supports one-touch
play) automatically turns on and switches to the
video-in channel. Disc play starts if there is a disc in
this player.
On
Enable one touch play feature
Off
Disable one touch play feature
) to return to the Video Setup
One Touch Standby
When you press and hold POWER button on RC,
all the connected HDMI CEC devices (if the device
supports one-touch standby) switch to standby
mode.
On
Enable one touch standby feature
Off
Disable one touch standby feature
Note:
If no display appears on the TV screen due to
unsupported resolution, reconnect any available
interlace video output to your display and re-
adjust the resolution settings to 480p/576p.

Preference Page

Notes:
You can't set TV type until HDMI is set to off.
TV Type
Pal
Select this when the unit is connected to a PAL
TV.
Auto
Select this when the unit is connected to a Multi
TV.
Ntsc
Select this when the unit is connected to an
NTSC TV.
PBC
Turn on or off the content menu of VCD/SVCD
with PBC (playback control) feature
on
Display the index menu when you load a disc
off
Skip the menu and start play from the first title
Audio, Subtitle, Disc Menu
You can select a preferred language for audio,
subtitle and disc menu.
When you select a preferred language that is

not recorded on the DVD, one of the recorded
languages is automatically selected.
You can override the Audio setting in the Setup

menu by pressing the AUDIO button on the
remote control unit while a DVD is playing.
You can override the Subtitle setting in the Setup

menu by pressing the SUBTITLE button on the
remote control while a DVD is playing.
Select Off to turn subtitles off. Note that subtitles

on some discs cannot be removed even when
you select Off.
15
