Checklist - XYZ Printing Da Vinci nano w Guía Rápida

Software Setup
Printing
＊ For better printing results, we recommend that you calibrate before printing.
Before printing, please use the USB cable or WiFi to connect the computer and your 3D printer to proceed the loading
filament function.
Click [Import]. Import your favorite 3D files. Click on
01
the object to adjust the size you need.
When you're done adjusting the print parameters you
03
need, click [PREPARE].
When the print job begins, the printer will print a line
05
on the print bed to ensure the filament is extruding
properly.
•
When the printer starts printing, you can monitor the status by clicking [DASHBOARD].
Note
•
The recommended operating temperature is 15℃ ~ 32℃ (59 ℉ ~ 90 ℉ ). If the room temperature is above this, please open
the front cover to maintain print quality.
•
After the print is finished, the object may be removed with a scraper.
•
When using different types of filament, we recommend changing the extruder module.
When the object is adjusted, you can start printing.
02
After preparing, please check if the object is a complete
04
model. After the confirmation, click [PRINT].
Check List
 Setup your 3D printer
 Download XYZmaker Suite
 Load Filament
 Try to print a sample
Start to Create!
7
