PACKAGE CONTENTS

G H
I
PART DESCRIPTION
A Trigger switch
B Rear handle
C Lock-off button
D Front handle
E Chain kickback brake handle
F Side-cover knob
WARNING
• Remove the tool from the package and examine it carefully. Do not discard the carton or
any packaging material until all parts have been examined.
• If any part of the tool is missing or damaged, do not attach the battery or use the tool until
the part has been repaired or replaced. Failure to heed this warning could result in serious
injury.
F E
J K
D
PART DESCRIPTION
G Chain-tensioning knob
H Side cover
I Guide bar
J Saw chain
K Oil-tank cap
L Chain sheath
