Panel Dimensions
Extra-Large Panel (277/347 V
Dimensions are in inches (mm).
82.0
(2083)
Left Side
R
(continued)
only)
22.0
(559)
Top View
23.50
3.0
(597)
(76)
3.45 (88)
68.0
(1727)
82.50
(2096)
18.5 (470)
22.75 (578)
Front View
Bottom View
Cover
Right Side
6.1 (155)
Installation Guide for Switching Panels
6.3
(160)
0.15
(4)
