Instructions for use

WARNING!
Before carrying out any work on the angle
grinder, always pull out the mains plug.
Before switching on the power tool
Unpack the angle grinder and check that
there are no missing or damaged parts.

Attach the guard

WARNING!
When using the angle grinder for roughing
or cutting, never work without the guard.
Fig. 
Pull out the mains plug.
Attach the guard. Lugs on the guard
hood must be located in the flange
recesses.
Turn guard hood clockwise.
Rotation is possible in one direction
only!
Remove in reverse order.

Adjusting the guard

To adjust the tool to the task at hand, the
guard hood can be adjusted by 12 notches
on 360° without a tool.
CAUTION!
Risk of injury! Wear protective gloves.
Fig. 
Pull out the mains plug.
Turn guard hood opposite to the
direction-of-rotation arrow on the gear
head to the required position.
Attaching/changing the tool
Pull out the mains plug.
Attach the sanding disc
Fig. 
Remove the handle from the power tool
by rotating it in an anti-clockwise
direction.
Rotate the cover on the handle by 180°
until it engages. The stop key is
released.
20
Fig. 
Press and hold down the spindle
lock (1.).
Using the stop key, loosen the clamping
nut on the spindle in an anti-clockwise
direction and remove (2.).
Insert the grinding wheel in the correct
position.
Fig. 
Screw the clamping nut with flange face
up, onto the spindle.
Press and hold down the spindle lock.
Tighten the clamping nut with the stop
key.
Carry out a test run to check that the tool
is clamped in the centre.
Attaching the Velcro pad (L 3406 VRG only)
Remove the guard.
Press and hold down the spindle lock.
Using the stop key, loosen the clamping
nut on the spindle in an anti-clockwise
direction and remove.
Remove clamping flange.
Fig. 
Screw Velcro pad clockwise onto the
spindle and tighten hand-tight.
Place the sanding tool in the centre of
the Velcro pad and press on.
Carry out a test run to check that the tool
is clamped in the centre.
Test run
Insert the mains plug into the socket.
Switch on the angle grinder (without
locking into position) and leave the angle
grinder running for approx. 30 seconds.
Check for imbalances and vibrations.
Switch off the angle grinder.

Switching on and off

Brief operation without engaged switch
rocker
Fig. 
First press the starting lockout.
Then press and hold down the switch.
Release switch interlock.
To switch off, release the switch.
Angle grinder
