ARTEMIS / TX-FIT SERIES
TRANSMITTERS
TRANSMITTER DATA STORAGE
m
CAUTION: The data storage of the first transmitter
determines the direction of motion of the motor.
m
CAUTION: If the awning has a casing, carry out the data
storage of the first remote control by following the procedure
"TRANSMITTER DATA STORAGE"
To store your remote controls on a blank control unit which
drives a shutter or an awning (WITHOUT casing) proceed as
follows:
1. Press and hold the R1 button on the receiver: after 2 seconds
the L1 LED turns on
2. Activate the programming by following one of these
procedures
Transmitter with 1 channel:
•
Press and hold the UP+DOWN keys until the motor starts
to move in one direction
Transmitter with 2 channels:
•
Press the UP+DOWN keys of one of the two channels until
the motor starts to move in one direction
Transmitter with 6 channels:
•
Select the channel to be programmed with the C key
•
Press the UP+DOWN keys until the motor starts to move in
one direction
3. Release the keys: the motor stops
4. Press the UP or DOWN keys according to the direction in
which the roll-up shutter was moving before it stopped:
-
if the roll-up shutter was going up press the UP key;
direction obtained: the UP key moves the roll-up shutter
upwards, the DOWN key moves the roll-up shutter
downwards
-
if the roll-up shutter was going down press the DOWN
key; direction obtained: the DOWN key moves the roll-up
shutter downwards, the UP key moves the roll-up shutter
upwards.
5. Programming is complete
To add remote controls, proceed as follows:
6. Press and hold down the UP+DOWN keys of an already
programmed remote control until the motor starts to move in
one direction
7. Release the keys: the motor stops
8. Press the UP or DOWN key of the new remote control
DELETION OF ALL STORED TRANSMITTERS
To delete all codes stored with a transmitter proceed as
follows:
1. Activate the transmitter programming
2. Press the UP or DOWN keys until the LED 3 light is fixed and
the others flash
3. Press and hold the UP+DOWN keys until the motor moves in
both directions, which confirms the correct deletion of the
codes.
4. Release the keys
5. To exit programming, wait for the LEDs to turn off
To delete all codes NOT stored with a transmitter proceed
as follows:
1. Press and hold the R1 button on the receiver: after 2 seconds
the L1 LED turns on
2. Activate the transmitter programming
3. Press the UP or DOWN keys until the LED 3 light is fixed
4. Press and hold the UP+DOWN keys until the motor moves in
both directions, which confirms the correct deletion of the
codes.
5. To exit programming, wait for the LEDs to turn off
- 13 -
