Pelican MityLite 1900 Instrucciones De Operación

"TECHNICALLY ADVANCED POWERFUL POCKET LIGHT"
MityLite
Patent No. D303 846
PRE-FOCUSED XENON FIRED
LASER SPOT BEAM
2 AAA ALKALINE ENERGIZER
BATTERIES INCLUDED
OPERATING INSTRUCTIONS CAT.#1900
MityLite
BATTERY INSTALLATION
1. Remove lens housing by turning counter-clockwise.
2. Remove the lamp module.
3. Remove used batteries and replace with fresh batteries + end up.
4. Replace the lamp module.
5. Replace lens housing squarely on threads and turn clockwise while slightly pressing on
the lens housing.
ON/OFF
Turn the lens housing clockwise until light activates. To turn light off, back lens housing off
counter-clockwise until light goes off. Continue to BACK OFF FOR APPROXIMATELY 1 FULL
TURN TO ELIMINATE POSSIBILITY OF LIGHT ACTIVATING ACCIDENTALLY IN STORAGE. Do
not overtighten.
LAMP REPLACEMENT
To replace the lamp module follow steps in the battery installation section as listed above:
To remove lamp module follow steps #1 and #2.
To replace lamp module follow steps #4 and #5.
CAUTION: If light is not to be used for some time, remove batteries to prevent possible
leakage and corrosion.
LENS DISC INSTALLATION
The colored discs are designed to enable the flashlight to be used without affecting night
vision. The discs fit inside the flashlight in between the lamp module and the inside of the
clear lens cover.
To Install:
1. Remove the lens cover.
2. Place the colored disc inside the lens cover.
3. Refit the lens cover.
HYDROGEN GAS ABSORBER
Internal catalyst pellets, located on the lamp, are there to help absorb hydrogen gas that
could possibly be emitted by defective, leaking, reversed polarity or heavily discharged bat-
teries. If the pellets become lost or damaged, replace lamp immediately. If pellets become
wet, let them air dry. Pelican Products assumes no liability for any brand of batteries which
are defective or cause injury to anyone when used in any Pelican flashlight.
PRODUCT SPECIFICATIONS
Lamp Type:
Battery Brand:
Battery Type:
REPLACEMENT PARTS
CAT# DESCRIPTION
1901 O-RING
WARNING –
WARNING –
WARNING:
WARNING!
WARRANTY RETURN POLICY
Send all items for repair or replacement directly to Pelican Products Customer Service Dept.
(postage paid). Please call for a return authorization number. Per our guarantee, Pelican Products
will replace or repair any broken or defective products. Upon receipt of goods, Pelican Products
will notify you of any handling and return postage charges. If your local retailer does not stock the
above accessory parts, you may order them directly from Pelican Products. Send check or money
order in U.S. dollars, or order by phone using MasterCard or VISA (ask for Customer Service).
SORRY, NO C.O.D.'s. Subject to sales tax. Allow 2-3 weeks delivery time. Pelican Products pays
postage and handling charges. POSTAGE PAID FOR U.S. ZIP CODES ONLY.
PELICAN LEGENDARY LIFETIME GUARANTEE OF EXCELLENCE
Pelican Products, Inc. guarantees its products for a lifetime against breakage or defects in
workmanship. This guarantee does not cover the lamp or batteries (rechargeable or alkaline).
Any liability, either expressed or implied, is limited to replacement of the product. This guarantee
is void if the Pelican product has been abused beyond normal and sensible use. This guarantee
does not cover shark bite, bear attack or damage caused by children under five. Lifetime Guarantee
does not cover Roto Molded or AALG products. Refer to www.pelican.com/warranty for full details.
MityLite
INSTALACIÓN DE PILAS
1. Quite el bastidor de la lente haciéndolo girar en sentido contrario a las agujas del reloj.
2. Quite el módulo de bombilla.
3. Quite las pilas usadas y reemplácelas con pilas nuevas, con el polo + hacia arriba.
4. Vuelva a colocar el módulo de bombilla.
5. Coloque el bastidor de la lente sobre la rosca y gírelo en sentido de las agujas del
reloj mientras efectúa una presión leve sobre la misma.
ENCENDIDO/APAGADO
Gire el bastidor de la lente en sentido de las agujas del reloj hasta que se encienda la linterna.
Para apagar la linterna, gire el bastidor de la lente en sentido contrario a las agujas del reloj
hasta que se apague la linterna. Continúe GIRANDO EN TAL SENTIDO APROXIMADAMENTE
UNA VUELTA COMPLETA PARA ELIMINAR LA POSIBILIDAD DE QUE LA LINTERNA SE ACTIVE
ACCIDENTALMENTE MIENTRAS ESTÁ FUERA DE USO. No apretar en exceso.
REEMPLAZO DE LA BOMBILLA
Para reemplazar el módulo de bombilla siga los pasos indicados en la sección para la
instalación de pilas, tal como se indica a continuación: Para quitar el módulo de bombilla siga
los pasos 1 y 2. Para reemplazar el módulo de bombilla siga los pasos 4 y 5.
ATENCIÓN
Si no se piensa utilizar la linterna durante algún tiempo, quite las pilas para impedir cualquier
fuga o corrosión.
INSTALACIÓN DE DISCOS PARA LENTE
Los discos de colores fueron diseñados para permitir el uso de la linterna sin afectar la visión
nocturna. Los discos caben dentro de la linterna, entre el módulo de la bombilla y el interior de la
cubierta transparente de la lente.
Para instalar:
1. Retire la cubierta de la lente.
2. Coloque el disco de color dentro de la cubierta de la lente.
3. Vuelva a colocar la cubierta de la lente.
23215 EARLY AVE., TORRANCE, CA 90505 • Tel (310) 326-4700 • FAX (310) 326-3311
www.pelican.com
All trademarks and logos displayed herein are registered and unregistered trademarks of Pelican Products, Inc. and others.
Eveready & Energizer are a registered trademarks of Eveready Battery Company, Inc.
1900
TM
Xenon
®
Eveready Energizer,
E92 1.5V Alkaline AAA-cell (2)
EXPLOSION HAZARD – BATTERIES MUST ONLY BE CHANGED
IN NON-HAZARDOUS LOCATIONS
EXPLOSION HAZARD – SUBSTITUTION OF COMPONENTS MAY
IMPAIR SUITABILITY FOR USE IN HAZARDOUS LOCATIONS
Do not open light in a Hazardous location.
STATIC HAZARD --- Clean only with a damp cloth.
1900
TM
Part #1903-311-100
1900
TM
BY PELICAN
PELICAN LEGENDARY
LIFETIME GUARANTEE
®
® ®
Duracell
CAT#
1974
5-0697 Rev B
SUBMERSIBLE
Lamp Life:
20 hours
DESCRIPTION
LAMP MODULE
© 2010 Pelican Products JY/10
