MP3 RECORDER AND PLAYER

1
1. Power key: Push to turn the digital recorder on and off.
2. Up key: When wanting to select a track, push this
button to scroll through the tracks in ascending
order. Hold it down for two seconds to run through
the track numbers faster (this function will not work
in MP3 mode).
3. Back key: When wanting to select a track, push
this button to scroll through the tracks in descending
order. Hold it down for two seconds to run through
the track numbers faster (this function will not work
in MP3 mode).
4. Record key: Select track number when in VOC
mode and push REC key to record on the current
track. Push the stop button to stop recording. If
the track you want to record on is already used,
the LCD will show "≣≣"and you must delete the
content of the track before recording. When the in-
built memory only has 30 seconds left, the LCD will
start to count down the remaining time. You can use
a microphone, a line in audio source or a mixture of
both as your recording source.
Note: If you want to record to an SD card or Flash
memory, you must push Mode and stop button
together to switch from C to F (as indicated in front
of the time).
5. Play/Pause key: Select the track you want to play
then push this key to play. Push this key again
during play to pause the track.
6. Stop key: Push the key to stop all functions, for example
recording, play back, track selection, etc.
7. Forward key: Pushing this key will skip forward
through the track currently playing. The track will
resume as normal when the key is released.
8. Rewind key: Pushing this key will rewind through
the track currently playing. The track will resume as
normal when the key is released.
9. A-B repeat key:While playing, push this key to
indicate any point as start point (A point) and push
again to indicate a finish point (B point). The device
will repeat from A to B point until you push the key
again to release the function and continue to play.
8
3
4
12 13 14
Sound Ambassador 75 Deluxe / Sound Ambassador 120 Deluxe
8
10
9
2
6
15
16
11
10. Repeat key: When playing in MP3 mode, push
this key once to simply repeat a single track. Press
repeat a second time to repeat all tracks. Push the
key at the third time to release repeat function. This
function can not be used in VOC mode.
11. Volume controls: There are two main volume
controls; the Mic input controls the microphone input
level, whereas the remaining volume control adjusts
the output level.
12. Earphone: for connecting headphones
13. USB: for connecting to a PC
14. SD card: for an SD memory card up to 1 GB
(When a 512 MB SD card is used, the recording
time available is over 8 hours.)
15. Microphone: Connect up to two microphones. If
only one microphone is used, use the left input.
16. Mode Key: Push the MODE key with another key
for special function selection. The LCD will show
"MODE" when pushed. If you do not push another
function key within 5 seconds, the machine will
return to idle mode. The following are the details of
special function keys.
1. MODE + Up: LCD will show "LINE IN", and
select line in audio source as recording source.
2. MODE + A-B: allows you to use different
EQ presents. EQ functions will arrive in the
following sequence: Normal, Classic, Pop,
Rock, Jazz.
3. MODE + Rewind: Use this select VOC mode
(allowing you to record from microphone or
LINE IN source) or MP3 mode (allowing you to
download mp3 files from PC).
4. MODE + Forward: When these two keys
are pushed, the LCD will show "DEL." Push
Forward (ie. Del) key again to delete the track.
The LCD will show "DEL" until the delete
process is finished.
MODE + Stop: Change between the flash and
5.
SD card when in play or idle mode.
7
5
