TABLE 3
Operating environment
Operating Temperature
0° – 40° C (32° – 104° F)
TABLE 4
Storage environment specifications
Storage Temperature
40° to 70° C
(-40° to 158° F)
•
Mechanical loading: Do not place any equipment on top of a rack-mounted unit.
•
Circuit overloading: Be sure that the supply circuit to the rack assembly is not overloaded.
•
Grounding: Rack-mounted equipment should be properly grounded. Particular attention should be given to
supply connections other than direct connections to the mains.
Use the following steps to mount devices in rack.
1. Remove the rack mount kit from the shipping carton. The kit contains two L-shaped mounting brackets and
mounting screws.
2. Attach the mounting brackets to the sides of the device as illustrated in
NOTE
B-FCX624-E, B-FCX624-I, B-FCX648-E, and B-FCX648-I device brackets are mounted using three screws, as shown in
Figure 5.
FIGURE 4
Attaching the Brackets for B-FCX624S and B-FCX648S devices
12
All manuals and user guides at all-guides.com
Relative Humidity
5 to 95%, @ 40° C (104.9°F), non-condensing
Storage Humidity
95% maximum,
non-condensing
Operating Altitude
0 – 3000 meters (10,000 feet)
Storage Altitude
3,000 meter (10,000 feet)
maximum
Figure 4 and Figure 5.
