Connectors (Per System Board)
Back
NIC
COM
USB
Video
Management port
Internal
Micro-SD socket
Video (Per System Board)
Video type
Video memory
Power
NOTE: The system doesn't support a mixed installation of 1200 W and 1400 W power supplies.
NOTE: Both of these two PSUs are swappable, and they can support hot swap in any condition if
system has power throttling feature.
AC power supply (per power supply)
Wattage
Voltage
Heat dissipation
Maximum inrush current
Getting Started With Your System
Two RJ-45 (10/100/1000 Mbps Ethernet)
9-pin, DTE, 16550-compatible
Two 4-pin, USB 2.0-compliant
15-pin D-Sub VGA
RJ-45 Ethernet port for remote management
access. The management LAN speed is
10Mbps/100Mbps.
SD riser card memory socket
AST2300 on-board video controller, or
AST1300
16 MB
1200 W
100-240 VAC, 50/60 Hz, maximum input
current: 12.0-8.0 Amps
NOTE: For 1200 W power supply, output 1200 W is for
high line (input 200-240 VAC), output 1023 W is for low
line (input 100-120 VAC).
4016.251 BTU/hr maximum
Initial In-rush Current cannot exceed
55 Amps (peak). Secondary In-rush Current
cannot exceed 35 Amps (peak).
