1. Unpacking Your Fan.

Carefully open the packaging. Remove items
from Styrofoam inserts. Remove motor assembly
and place on carpet or Styrofoam to avoid
damage to finish. Do not discard fan carton or
Styrofoam inserts should this fan need to be
returned for repairs.
Check against parts inventory that all parts have
been included.

2. Parts Inventory.

c. downrod and hanging ball. 1 piece
f. remote control cover. 1 piece
i. canopy cover (in hardware pack). 1 piece
IMPORTANT REMINDER: You must
use the parts provided with this fan for
proper installation and safety.
a. canopy. 1 piece
b. hanging bracket. 1 piece
d. wall control. 2 pieces
e. wall plate.1 piece
g. faceplate. 3 pieces
h. yoke cover. 1 piece
j. motor assembly. 1 piece
k. fitter plate. 1 piece
l. LED light kit. 1 piece
m. glass shade. 1 piece
n. hardware packs
a
d
e
III
IV
II
V
VI
I
i
h
j
k
m
n
w/wall controls
page 2
c
b
g
f
l
OFF
ON
