Total vibration values (vector sum of three direc-
tions) determined in accordance with EN 62841.
Warning!
The specifi ed vibration value was established in
accordance with a standardized testing method. It
may change according to how the electric equip-
ment is used and may exceed the specifi ed value
in exceptional circumstances.
The specifi ed vibration value can be used to
compare the equipment with other electric power
tools.
The specifi ed vibration value can be used for initi-
al assessment of a harmful eff ect.
Keep the noise emissions and vibrations to a
minimum.
•
Only use appliances which are in perfect con-
ditions.
•
Service and clean the appliance regularly.
•
Adapt your working style to suit the appliance.
•
Do not overload the appliance.
•
Have the appliance serviced whenever ne-
cessary.
•
Switch the appliance off when it is not in use.
•
Wear protective gloves.
Residual risks
Even if you use this electric power tool in
accordance with instructions, certain resi-
dual risks cannot be rules out. The following
hazards may arise in connection with the
equipment's construction and layout:
1. Lung damage if no suitable protective dust
mask is used.
2. Damage to hearing if no suitable ear protec-
tion is used.
3. Health damage caused by hand-arm vib-
rations if the equipment is used over a pro-
longed period or is not properly guided and
maintained.
5. Before starting the equipment
Before you connect the equipment to the mains
supply make sure that the data on the rating plate
are identical to the mains data.
Warning!
Always pull the power plug before making
adjustments to the equipment.
Anl_TC_SM_2131_1_Dual_SPK8.indb 44
Anl_TC_SM_2131_1_Dual_SPK8.indb 44
GB
5.1 General information
•
The equipment must be set up where it can
stand securely, i.e. it should be bolted to a
workbench, a universal base frame or similar.
•
All covers and safety devices have to be pro-
perly fitted before the equipment is switched
on.
•
It must be possible for the blade to run freely.
•
When working with wood that has been pro-
cessed before, watch out for foreign bodies
such as nails or screws, etc.
•
Before you actuate the On/Off switch, make
sure that the saw blade is correctly fitted
and that the equipment's moving parts run
smoothly.
5.2 Assembling the saw (Fig. 1-5)
•
Fit to the locking screw (14) to the turntable
(17).
•
Fit the workpiece supports (10) on the left
and on the right of the fixed saw table (18).
Do this with the socket head screws (39) and
the 5mm hex key (40).
•
To fit the sawdust bag (22) to the discharge
opening (23) on the crosscut saw, spread the
metal ring apart on the opening. When the
metal ring is back in its original shape, the
sawdust bag is held securely in position.
•
The clamping device (8) can be fitted on the
left or right of the fixed saw table (18).
5.3 Adjusting the saw (Fig. 1-3)
•
To adjust the turntable (17), loosen the
locking screw (14) by approx. 2 turns, which
frees the turntable (17).
•
Turn the turntable (17) and scale pointer (15)
to the desired angular setting on the dial (16)
and lock into place with the locking screw
(14). The saw has locking positions at angles
of - 45°, -31.6°, -22.5°, -15°, 0°, 15°, 22.5°,
31.6° and 45°, at which the turntable (17) au-
dibly clicks into position.
•
To release the saw from its position at the bot-
tom, pull the retaining pin (25) out of the
motor mounting while pressing down lightly
on the machine head (4).
•
Swing the machine head (4) up until the re-
lease lever (3) latches into place.
•
To adjust the machine head (4) for a miter cut,
slacken the locking lever (21).
•
Then you can tilt the machine head (4) to the
left by up to 45°. After the desired angular set-
ting has been set on the scale pointer (20) on
the scale (19), secure the machine head (4)
•
again with the locking lever (21).
- 44 -
