Using a Memory Card (WK-500 Only)
• You can input the following characters in a file name.
0 1 2 3 4
A B C D E
K L M N O
U V W X Y
( ) - ^ {
• The Digital Keyboard displays the "~" character as "3".
■ SD Memory Card Data (File) Storage Locations
The above procedure stores Digital Keyboard data in a folder
named "MUSICDAT" on the SD memory card.
• The "MUSICDAT" folder is created automatically when you
format the SD memory card on the Digital Keyboard (page
E-60).
• If you store a file in any location other than inside the
"MUSICDAT" folder, you will not be able to recall, delete, or
play the file on the Digital Keyboard. You also will not be
able to recall, delete, or play any file you store inside of a
subfolder you create inside the "MUSICDAT" folder.
• The message "No File" will appear on the display if you try
to perform a recall, delete, or play operation while there is
no file inside the "MUSICDAT" folder.
E-62
All manuals and user guides at all-guides.com
5 6 7 8 9
F G H I J
P Q R S T
Z S & _ '
} @ ~ `
Loading Data from an SD Memory
Card into Digital Keyboard
Memory
Use the following procedure to load data from an SD memory
card into Digital Keyboard memory.
• Whenever you copy a file to the SD memory card that
you plan to recall on the Digital Keyboard, be sure to
store the file in the SD memory card's "MUSICDAT"
folder.
1.
On the Digital Keyboard, select the data you
want to load as described below.
To load this type
of data
Sampled sound Select the tone number of the sampled
sound you want to load.
User rhythm Select the rhythm number of the user
rhythm you want to load.
User song Select the song number of the song you
want to load.
Recorded song Select the song you want to load and
put the Digital Keyboard in playback
standby.
bq
User scale Press and then
memory
Registration data Select one of the Digital Keyboard's
default built in tones, songs, rhythms,
All data
etc.
2.
Insert the SD memory card that contains the
data into the Digital Keyboard's card slot.
3.
dk
Hold down until the button lights.
• To cancel data load, press
4.
bs
Use the (10-key) [4] (
to display one of the settings shown below.
• You also could use [–] and [+].
To load this data Display this screen
Sampled sound "Lod" "SmplTone"
User rhythm "Lod" "UserRhy."
User song "Lod" "UserSong"
Recorded song "Lod" "Rec.Song"
User scale memory "Lod" "ScaleMem"
Registration data "Lod" "Regist."
All data "Lod" "All Data"
Do this
4
.
dk
again.
) and [6] ( ) keys
