EN
Mulching using the accessories (optional)
With mulching, the grass is cut into small pieces
(approx. 1 cm) during mowing and is left on the
ground. A lot of the nutrients in the cut grass are
Ask your specialist dealer for appropriate mulching
accessories.
Note
This device is designed to mow lawns. Do
not mow scrub, weeds, or overlong grass.
Pay attention to the following notes:
Do not mow any wet grass, and never more
than max. 2 cm.
Mow the entire length of grass.
Drive slowly and at maximum engine speed.
Clean the lawn mower deck regularly.

Switching the device off

Stop the device.
Switch the cutter deck off.
Set the throttle to the middle position.
Bring the cutter deck to the top position.
Switch the engine off after 20 seconds.
Switch the parking brake on.
Shut the fuel tap.
Remove the ignition key.
Pushing the device
Switch the engine off.
Switch the parking brake off.
Pull both gear release levers (near the left and
right rear wheel) back and press them downwards
into the recess.
You can now push the device.
Note
Never tow the device. This can cause seri-
ous damage to the gears.
To continue driving, pull both gear release levers
out from the recess and push them forwards.
20

Display cluster (depending on the model; optional)

Display cluster (depending on the model;
optional)
Note
The indicators only appear when the engine
is running.
Note
occur at the same time, the oil change
indicator.
Depending on the model, the display cluster can
consist of the following elements
1 Oil pressure If this indicator light is illuminated
when the engine is running,
switch the engine off immediately
and check the oil level. If nec-
essary, pay a visit to a service
centre.
2 Brake This indicator lamp lights up if the
brake pedal is not depressed or
the parking brake is not locked
when the engine starts.
3 Cutter deck This indicator lamp lights up
(PTO) when the cutters are not switched
OFF at engine start (PTO).
4 Battery charge This indicator light lights up with
indicator the engine running if the bat-
necessary, pay a visit to a service
centre.
5 Operating When the ignition is switched on,
hour counter the battery voltage indicator is
displayed for a short period, which
then changes to the operating
hours indicator. The operating
hours are displayed in 1/10 hours.
The operating hours are always
counted except for when the igni-
tion key is in the "Stop" position or
when it is removed.
Note
means: The total operating hours are
displayed.
:
