EN • 8

Bottom panel

Figure 2: Description of bottom panel
No.
Connector
1.
PC Audio In
2.
YPbPr
3.
Audio In 3
4.
VGA
5.
DVI
6.
DC Out
7.
DC In
Description
PC phone jack for audio source of RGB output terminal.
Connect to the component input terminal of video equipment such as a
DVD.
Audio source with YPbPr.
Connect to a RGB input terminal, such as the display card output DVI
terminal of the personal computer.
Connect to a digital RGB input terminal, such as the display card output
DVI terminal of the personal computer (PC).
12 VDC Out for single camera power (max. 500 mA).
Plug head of a DC jack with 12 V / 4 A adapter.
UltraView LCD 17 in./19 in. Monitor
