Interface
11: Autonomy limitation setting
Interface
12: Battery total AH setting
Interface
13: Maximum charger current setting
Interface
14: Charger boost voltage setting
Interface
15: Charger float voltage setting
Setting
Parameter 2: Set the backup time limits for programmable
outlets.
0-999: Set the backup time limits in minutes from 0-999 for
programmable outlets which connect to non-critical devices
on battery mode. (Default: 999)
Setting
Parameter 2: Set the backup time on battery mode for
general outlets.
0-999: Set the backup time in minutes from 0-999 for general
outlets on battery mode.
DIS: Disable the autonomy limitation and the backup time will
depend on battery capacity. (Default)
Note: Setting to "0", sets backup time to just 10 seconds.
Setting
Parameter 2: Set the battery total AH of the UPS.
7-999: Setting the battery total capacity from 7-999 in AH.
Please set the correct battery total capacity if external battery
bank is connected.
Setting
Parameter 2: Set the charger maximum current.
1/2/4/6/8: Set the charger maximum current 1/2/4/6/8 in
Ampere. (Default: 2A)
Note: Set the appropriate charger current based on battery
capacity used. The recommended charging current is
0.1C~0.3C of battery capacity as following table for
reference.
Battery capacity (AH)
7~20
20~40
40~60
60~
Setting
Parameter 2: Set the charger boost voltage.
2.25-2.40: Set the charger boost voltage from 2.25 V/cell to
2.40V/cell. (Default: 2.36V/cell)
12
Total charging current (A)
2
4
6
8
