Interface
④
②
①
③
⑤
⑥
⑦
⑧
⑨
⑩
⑪
RS-232/422/485
Pin
RS-232 Mode
RS-422 Mode
1 2
1
DCD
RS422 TX-
2
RxD
RS422 TX+
3
TxD
RS422 RX+
4
DTR
RS422 RX-
5
GND
Ground
6
DSR
n.c.
7
RTS
n.c.
8
CTS
n.c.
9
RI
n.c.
Mounting position
a
0 °C (32 °F) ≦ T
≦ 45 °C (113 °F)
a
a ≧ 50 mm (1.97")
2/4
XP-504-BOXPC-
a
SD-Slot
b
USB-Host 3.0
c
USB-Host 3.0
d
Ethernet 1 LAN
e
Ethernet 2 LAN
f
USB-Host 3.0
g
USB-Host 3.0
h
DP
i
HDMI
j
RS-232/422/485
k
Power Supply
RS485 Mode
3
4
5
6
7
8
9
RS485 Data+
RS485 Data-
CAN-GND
n.c.
GND
n.c.
n.c.
n.c.
n.c.
IEC/EN 60715
a
SD or SDHC (SDA Spezification 2.0, mind. 8 GB)
USB3.0 / 2.0, plug type A
USB3.0 / 2.0, plug type A
RJ-45 socket, 8-polig, 2 LEDs (CAT5e/6), LAN, 1000 Mbps
RJ-45 socket, 8-polig, 2 LEDs (CAT5e/6), LAN, 1000 Mbps
Dual-USB3.0 / 2.0 T, plug type A
Dual-USB3.0 / 2.0 T, plug type A
Display port socket
1.4b
SUB-D, via BIOS configurable; Default setting: RS 232 Full duplex
+24 VDC
1 mm (0.04")
7.5 mm (0.29")
15 mm (0.59")
