Mounting on
IEC/EN 60715
Mounting
Mounting with screw connection
Preparation
M3x5 (3/16")
TORX T10 A2 ISO14583
M ≦ 0.4 Nm (3.54 lb-in)
2x 4x
Mounting options, but fix both sides
1
2
M4
2.2 Nm
(19.47 lb-in)
M4
2.2 Nm
(19.47 lb-in)
Dismounting
T 2
M3x5
0.4 Nm
(3.54 lb-in)
M4
2.2 Nm
(19.47 lb-in)
3
1
2
M4
2.2 Nm
(19.47 lb-in)
