Setup
Important:
The battery pack is not fully charged
when you purchase it. Before using the tool for
the first time, refer to
(page 11).

Assembling the Blower

Slide the blower tube onto the blower housing. You
may need to press down on the tube latch for the
blower tube to lock into place
1. Tube latch
Charging the Battery Pack
(Figure 3).
Figure 3

Product Overview

1. Battery and battery cavity
2. Turbo boost button
g273147
3. Speed lock
4. Handle knob
1. Battery charger Model
88610 (included with
Model 51824)
8
Figure 4
5. Blower tube latch
6. Blower tube
7. Variable-speed trigger
Figure 5
2. Battery pack Model 88620
(included with Model
51824)
g335835
g330065
