ROBO Compact W500 / W600
1 Identification
The MIG/MAG welding torch is used to safely weld low and high-alloy materials.
The torch consists of:
• Torch neck with equipment parts and wear parts
• Cable assembly with equipment and cable support
The MIG/ MAG welding torch complies with EN 60974-7 and is not a device that can be used
in its own. Arc welding is only possible in conjunction with a welding power source.
The ROBO Compact W500 / W600 MIG/MAG welding torch is optionally available as
a version with wire brake.
These operating instructions only describe the ROBO Compact W500 / W600 MIG/MAG
welding torch. The MIG/MAG welding torch must only be operated using original
ABICOR BINZEL spare parts.
1
1
Torch neck
2
Insulating sleeve
Fig. 1
Product overview
1.1 Marking
This product fulfills the requirements that apply to the market to which it has been introduced.
A corresponding marking has been affixed to the product, if required.
2
3
3
Cable support housing on the torch
4
Cable assembly
5
Cable support housing on the machine
6
Nameplate, yellow
1 Identification
4
5
6
EN - 3
