TREATMENT SETUP
T T R R E E A A T T M M E E N N T T S S E E T T U U P P
T T R R E E A A T T M M E E N N T T T T I I M M E E
Press and release the TIME button. This
will cause the Treatment Timer Minutes
to flash.
Use the Up Arrow or Down Arrow
button to set the desired treatment
minutes. Range is 1 to 99 minutes in
one minute increments and continuous.
T T R R E E A A T T M M E E N N T T T T E E M M P P E E R R A A T T U U R R E E
Press and release the TEMP button. This
will cause the Treatment TEMP Degrees
to flash.
Use Up Arrow or Down Arrow button to
set the desired treatment temperature.
N N O O T T E E : : The factory default for the treatment temperature is °F. If you
want to display °C, press and hold the TEMP button for approximately
five seconds. This will cause the °F to flash. Use the Up Arrow or
Down Arrow button to set to °F or °C. The actual temperature range
attained may vary based on the room temperature and airspeed.
N N O O T T E E : :
Should the unit lose power, the main power switch is turned off, or
the unit is unplugged for a period exceeding one hour, the time
presets will be lost and will require re-setting. If the Preheat
Standby Mode has been programmed to "Enable", it will require the
time to be reset and the Preheat Auto Mode reset in order for the
Preheat Standby mode to function as desired.
C C H H A A N N G G I I N N G G D D E E F F A A U U L L T T S S E E T T T T I I N N G G S S
To set the desired time, temperature and air speed default settings,
after the desired changes are made, press and hold the Treatment
Start Button until "Current Values saved as Default Presets" is
displayed.
Save the default changes by pressing and holding the Stop button
until "Changes Saved" is displayed.
1 1 4 4
Fluido DHT ™ Dry Heat Therapy Unit
T T R R E E A A T T M M E E N N T T A A I I R R S S P P E E E E D D
Press and release the AIR SPEED
button. This will cause the Air Speed
percentage to flash.
Use the Up Arrow or Down Arrow
button to set the desired treatment air
speed. Range is from 5% to 100% in
5% increments.
