Symbol Definitions

The following symbols are located on the Chattanooga Group Fluido DHT Dry Heat Therapy Unit Control Panel. Understand the meaning
of each symbol before attempting any operation or use of the unit.
This symbol indicates therapy session time adjustment.
This symbol indicates therapy session temperature
adjustment.
This symbol indicates therapy session air speed
adjustment.
This symbol indicates upward adjustment in function
parameters.
This symbol indicates downward adjustment in function
parameters.
This symbol with the illuminated blue indicator light
indicates the Intake Filter requires changing.
This symbol with the illuminated blue indicator light
indicates the Cellex ® media requires changing.
This symbol indicates start therapy session.
This symbol indicates stop therapy session.
This symbol indicates Pulse Mode for pulse therapy
sessions.
This symbol indicates Preheat Standby function.
